   Service Overview and Features
ライン

Input Data Support for 3D Laminated Plates、and Differential Crack Models

1.Analysis Using Flat Plate Elements
  • By using the flat plate element, it is possible to analyze a structure that has walls as structural points. In addition, the Maekawa model (Dispersion Crack Model), which is a globally acclaimed reinforced concrete nonlinear constitutive law is used, and it is possible to analyze not only in-plane deformation but also out-of-plane deformation nonlinear behavior. As the analysis continues, the displacement and status of the cracks can be displayed. We support various modeling such as plate model analysis of bridge floor slab, plate modeling analysis of foundation floor slab, underground wall structure.

2.Analysis Using Fiber Elements
  • As a nonlinear analysis of beam elements, UC- win/FRAME(3D) analysis using fiber elements is possible. Appropriate analysis is possible for structures in which axial force fluctuations or bi-axial bending occur, such as bidirectional vibrations on bridge piers and nonlinear analysis of steel bridges.

▲Example of simultaneous loading
(planar display)

▲Results of the
analysis of a flat plate
element resembling
a RC beam


Example Analysis

▲Nonlinear dynamic analysis of a bridge with locking piers during a level 2 earthquake ▲Analysis result of reinforcement model using fiber element


Reservoir Analysis Support Service

Using earthquake-resistant construction designs and guidelines for water supply facilities, in accordance with the Japan Waterworks Association’s 2009 “Static nonlinear analysis for water storage” , a complete Push-over analysis can be achieved using Engineer’s Studio or UC-win/FRAME(3D).

▲ Deformation and damage to concrete ▲ Concrete damage on middle pillar
And stress strain history
▲Comparison with design casebook analysis results
▲Cross section of Beam ▲Concrete ▲Rebar
▲Reservoir plate model dynamic nonlinear analysis

  Analysis Support Service Packagesライン
5-Pillar, 3 Spans, Hollow Floor,
Locking Pier Bridge Package
●Non-linear Analysis、Uses M-φ
●Nodes=98
●Sectional Elements=61
●Flat Plate Elements=0
●No data creation from nodes, Data is created
from blueprints and design calculations
●Bearing and foundation's spring constant is given

Price
 $6,612.41USD  (Exc. Tax)
5 Span Continuous Girder Bridge Package
●Non-linear Analysis, Uses M-φ
●Nodes=63
●Cross-Sectional Elements=24
●Flat Plate Elements=0
●No data creation from nodes,
Data is created from blueprints and design calculations
●Support and foundation Spring constant is given

Price  $4,694.87USD   (Exc. Tax)
RC Arch Bridge
●Non-linear Analysis、Uses Flat Plate Element
(Dispersion Crack Model)
●Nodes=272
●Cross-Sectional Elements=14
●Flat Plate Elements=10
●No data creation from nodes, Data is created from
blueprints and design calculations
●Support and foundation's spring constant is given
Price  $9,320.17USD (Exc. Tax)
Suspension Bridge
●Linear analysis, Using cable elements
●Nodes=124
●Cross-Sectional Elements=20
●Flat Plate Elements=0
●No data creation from nodes,
Data is created from blueprints and design calculations
●Bearings and foundation's spring constant is given
Price  $5,487.00USD   (Exc. Tax)
Drainage, Gutter Package
●Non-linear Analysis、Uses M-φ
●Nodes=200
●Cross-Sectional Elements=30
●Flat Plate Elements=0
●No data creation from nodes, Data is created from
blueprints and design calculations
●Basic spring constant is given
Price  $11,737.16USD(Exc. Tax)
Weir Pillar / Gate Pillar
●Non-linear Analysis、Uses M-φ / M-θ elements
●Nodes=180
●Cross-Sectional Elements=40
●Flat Plate Elements=0
●No data creation from nodes,
Data is created from blueprintsand design calculations
●Basic spring constant is given
Price  $15,214.83USD  (Exc. Tax)
RC Reservoir
●Non-linear Analysis、Uses Flat Plate Element
(Dispersion Crack Model)
●Nodes=921
●Cross-Sectional Elements=15
●Flat Plate Elements=5
●No data creation from nodes, Data is created from
blueprints and design calculations
●Bearing and foundation's spring constant is given
Price  $23,710.02USD(Exc. Tax)
