UC-win/Road new features
@UC-win/Road Ver.8.00.00 (Release October 19)NEW
ƒ‰ƒCƒ“
LOD feature now applied to 3D models as well

  • LOD (Level Of Detail) is a technique for enhancing performance by changing the quality of an object according to its distance from viewpoint. In the older versions, LOD feature was applied when displaying characters, however in Ver.8, LOD feature can also be applied to 3D models and FBX scene models.
    Click the image for a larger picture. Click the image for a larger picture. Click the image for a larger picture.
    Model in 3 stages' quality Setting display of LOD model Example of setting LOD model in 3 stages

Expansion of driving simulation function

     -Improvement of automatic gearshift.
     -Automatic Transmission has been improved.
Click the image for a larger picture. Click the image for a larger picture.
Click the image for a larger picture.
Comparizon of shifting the timing
iAbove:Ver.7, below:Ver.8j
Setting screen of automatic gearshift

     -Manual Transmission has been improved.
     -ABS (Antilock Brake System) is now supported.

Improvement of terrain generation feature

      -Generation of large-scale terrainFLarge-scale terrain (exceeding area of 100km) can be generated.
      -Terrain size can be altered flexiblyFAny region within the map can be specified and generated easily.
      -More formats are supportedFFormats below can now be imported.
@            SRTM90i90m meshj, ASTERi30m meshj
              BlueMarbleNextGenerationi500m meshj *Seabed is also available
       -Assign resolution of terrainFResolution (number of patches) of terrain that need to be generated can be specified.

Click the image for a larger picture. Click the image for a larger picture.
Example of large-scale terrain
(between Tokyo and Nagoya)
Specifying the range
of terrain generation

Cluster scenario: Multimedia shown all on all PC

  • Previously, multimedia (image, video, text) were displayed only on control PC when you were running a scenario using cluster option (option sold separately), but from ver.8, multimedia are shown on slave PCs as well.

    Click the image for a larger picture.
    Example of scenario of cluster

Improvement of headlight display

         After a research on headlight standards in Japan and overseas, range of exposure and illumination pattern have been     improved to express exposure from headlights in a much more realistic manner. You can now switch around between low beam and high beam.

Click the image for a larger picture. Click the image for a larger picture.
Headlight of illuminated by an actual vehicle Headlight of UC-win/Road

Lighting feature has been enhanced

  • Light can now be assigned to any place on the 3D model, allowing users to add fog lamp and back lamp to their vehicle. Furthermore, headlights on vehicles within a traffic network or scenario can now be shown.

    Click the image for a larger picture. Click the image for a larger picture.
    Screen of defining the light of a model Expression of light of traffic flow

Number of mirrors

          From Ver.8, you can specify as many mirrors as you want. Therefore, cockpit with many mirrors such as that of trucks and other heavy vehicles can now be visualized much more accurately.

  • Click the image for a larger picture.
    Example of setting 6 mirrors

Improvement of sound effect

  • Vehicle sounds are much more realistic now that sound files of medium-sized vehicles have been improved and default sound profile of traveling vehicle has been improved.

Waypoint on an intersection

  • Waypoint can now be added in an intersection, allowing you to control vehicle speed within a traffic network or switch from one event to the another during a scenario.

    Click the image for a larger picture. Click the image for a larger picture.
    Waypoint on an intersection

Log Output plug-in (option that can be purchased by additional fee)

    We developed a new plug-in that logs the information on the coordinates, orientation, velocity, steering angle, etc. of driven vehicle (option that can be purchased by additional fee). Traffic flow and characters can also be output to CSV file format. The plug-in also has the ability to output UDP in real-time via network.


Log output data
Basic data Simulation time, model name, model ID, model type
Coordinates, position X coordinate, Y coordinate, Z coordinate, pitch angle, yaw angle, roll angle, vector
power, velocity Engine RPM, gear number, velocity (km/h, m/s), speed limit
Input Steering angle, accelerator position, brake position, autonomous driving
Example of log output data

Supports FBX 2013

  • Latest version of FBX file (FBX 2013) can now be imported. Collada file (*.dae) can now be imported much faster and its result are shown much more accurately. Many data including the ones created by SketchUp and 3D Gallery can now be used.
    Click the image for a larger picture.
    Imported Latest version of FBX file (FBX 2013)

EXODUS plug-in and micro simulation player plug-in has been expanded.


Vertical Railway Curve

  • Parabola of road and arc of a circle depicting a railway curve can now be drawn.

    Click the image for a larger picture.
    Setting screen of vertical railway curve

Loading parking model pluyg-in



@UC-win/Road@Ver.7.01.00 iRelease May 15, 2012jNEW
ƒ‰ƒCƒ“
Related Information@UC-win/Road Ver.7@(Up&Coming '12 Spring Issue)

@Supports horizontal curve of railroad

  • UC-win/Road has the ability to design roadfs horizontal curve using IP method. On top of that it has been added an ability to design cubic parabola commonly used in railroadfs horizontal curve and transition curve with half the length of sine wave, from the turning point.

@AutoCAD Civil 3D 2012i32bit^64bitjhas been supported.


@Enhanced off road driving function

  • A car that has once gone off the road can now rejoin traffic on the road and still be recognized by other vehicles on the road.

@Sky texture was added.

  • 8 kinds of textures for sky dome (Function to render a sky inside of the sphere) has been added.

@Option for road generation has been added.

  • Option to select a road regenerated on a road plate drawing when generating a road has been added. The road selected in this option is only regenerated to the road currently displayed which is not draft mode, so the work efficiency when editing will be greately improved.

@@UC-win/Road@Ver.7.00.00 iRelease April 12, 2012j
ƒ‰ƒCƒ“
Related Information@UC-win/Road Ver.7@(Up&Coming '12 Spring Issue)


@Cluster Optioniprice on applicationj

  • This system is a system that can synchronize two or more PC and output the image to a lot of monitors.
    It becomes possible to secure the constant performance without an influence from the number of channels.
£Flow of every flame £Synchronization of cloth, fire,
smoke, traffic vehicle and snow

@3D Model Output Plug-in iprice on applicationj

  • This is a plug-in to file output terrain, 3D model, road and tree etc. in 3ds format.
    This function outputs all models of geographical features in 3D space of UC-win/Road and the model, etc. in an arbitrary 3D model data format.
    For example, it will be possible to use it with various editors and tools such as 3ds Max by outputting it in 3ds format.
    Output TargetF Terrain, 3D model, road, tree (2Dj, road attachment (sign, tree, marking etc.).

@Off Road Function

  • The driving simulation of the vehicle is possible with a steering wheel controller, game controller and keyboard in UC -win/Road. However, you can drive only on the road, and when starting coming off from the road, you'll be compulsorily returned to correct driving line. Moreover, the driving simulation cannot be performed in the state that the road is not generated.

    This limitation was removed in UC-win/Road Ver.7, and it came to be able to drive anywhere freely in the VR space. It is possible to drive by getting off straight on terrain while driving on the road and also possible to begin to drive from the position by setting "Start point of driving" to an arbitrary position on terrain.

Click the image for a larger picture. Click the image for a larger picture.
£Setting of
the beginning point of driving
£Image of running in off-road

@xpswmm plug-in has been expanded.

  • Presentation function of simulation result of tsunami and flood has been enhanced.
£Reflection and inflection
of tsunami's water surface
£A few seconds later
from tsunami (Contour figure)

@Video card manufactured by ATI has been supported.

  • So far, the video card manufactured by NVIDIA is recommended for UC-win/Road, but the video card manufactured by AVI has been supported formally. It can be confirmed that most functions operate normally.

@Sidra Plug-in

  • It came to be able to do the import of the design data of latest version (Sidra Intersection 5.1) of intersection design software Sidra by revision of the Sidra plug-in. As a result, importing the shape, the section, the traffic signal control, and the traffic quantity etc. of the intersection designed by latest Sidra will be possible.

@Improvement of Rendering of Sky

  • The phenomenon that the texture of a sky is not drawn properly has been improved by the support of a video card manufactured by ATI.

@Function Expansion for CarSim

  • Version 7 is applied to the vehicle movement simulation using the set value of road friction coefficient ƒÊ.

@@UC-win/Road Ver.6.01.00 (Release March 8, 2012)
ƒ‰ƒCƒ“
World file

  • World file is a file with coordinates information standardized to give coordinates information to the street map (map images of the satellite photograph and the aerial photograph, etc.). By importing the street map together with World file, the street map will be automatically placed on top of the specific geographic location written in the World file.
Line Explanation
1 X scale ( Length(m) of each pixel along the X axis)
2 Rotation angle in X direction
3 Rotation angle in Y direction
4 Minus Y scale ( Length(m) of each pixel along the Y axis)
5 East longitude coordinates on the center of the pixel in the upper left corner of the image file.
6 North latitude coordinates on the center of the pixel in the upper left corner of the image file.

Fluid Analysis Plug-in (Price on applicatiom)

  • This plug-in is used to import a file in VTK format and visualize the stream line in the data used by the VTK format. The VTK format is a general format, so it's used for various software.
Click the image for a larger picture.

Munsell Color Space Output Plug-in (Price on application)

  • Munsell Color Space Output Plug-in is a plug-in which visualizes the spectacle displayed on the main screen of UC-win/Road in "Munsell color system" and saves it as munsell color file. This style of expression is often used in the field of design and art. You can design the spectacle using munsell color or do a research on munsell color by accessing the file that has been output using this plug-in.
Output image of munsell color file

@Legion Plug-in (Price on application)

  • Legion plug-in is a plug-in used to visualize analysis result of LEGION STUDIO, a software developed by a British company called Legion that simulates crowd movement. Legion accurately simulates the movement of pedestrians (entities) in a spatial area and then analyzes evacuation time, assess risks, and creates hazard map that can be utilized in the event of an emergency.
Click the image for a larger picture. Click the image for a larger picture.
Importing Legion file Setting of a profile and type
Click the image for a larger picture. Click the image for a larger picture.
Visualization example
of crowd simulation in a station
Crowd analysis result's linkage
with micro simulation player
@New version history
@@¡Ver.6 Ver.6.01.00 i2012/03/08j@@Ver.6.00.02 i2011/12/14j
@@¡Ver.5 Ver.5.00.00 i2010/09/21j@@Ver.5.00.03 i2011/01/26j@@Ver.5.00.05 i2011/07/05j
Ver.5.02.00 i2011/06/09j@@Ver.5.02.04 i2011/12/14j
@@¡Ver.4 Ver.4.00.03 i2010/04/08j@@Ver.4.00.01 i2009/12/09j
@@¡Ver.3 Ver.3.04.13 i2009/10/28j@@Ver.3.04.11 i2009/09/02j@@Ver.3.04.09 i2009/08/04j
Ver.3.04.07 i2009/06/26j@@Ver.3.04.06 i2009/05/19j@@Ver.3.04.05 i2009/04/10j
Ver.3.04.03 i2008/12/26j@@Ver.3.04.00 i2008/09/24j@@Ver.3.03.00 i2007/07/09j
Ver.3.02.11 i2006/11/24j@@Ver.3.02.00 i2006/09/07j@@Ver.3.01.00 i2005/12/22j
Ver.3.00.00 i2005/05/17j
@@¡Ver.2 Ver.2.01.00 i2004/09/09j@@Ver.2.00.00 i2004/06/03j
@@¡Ver.1 Ver.1.06.00 i2003/09/03j@@Ver.1.05.00 i2003/06/11j
Page Top Page Top

Program overview

UC-win/Road won the 2002 Software Product of the Year (Ministry of Economy, Trade and Industry).
It is advanced software that enables the creation of large scale 3D spaces for all sorts of projects by simple PC operations and with which you can give a variety of presentations in real-time.

3D VR data creation by simple operations is available. Practical data features include our standard database, a Web/Road Database and a LandXML data exchange function. It is equipped with an excellent VR creation / editing function for everything from road alignments, cross sections and terrain processing to traffic setup, model setup / processing, etc. Large-scale 3D spaces can be made by simple procedures in a surprisingly short time.

Visual option tools supporting several VR displays and presentation functions support the real-time presentation of landscape studies, design deliberations, project descriptions, etc. It has been utilized as a tool for building wide consensus for public works and developments by private constructors in general, as well as for road planning and design.

It assists engineering design, development and research whilst also supporting advanced simulation by sunshine simulation, traffic flow simulation, manual drive simulation, etc., in addition to drive simulation.

Page Top Page Top

UC-win/Road standard features



Standard / CAD Data Utilization
A 50m topographic mesh (of New Zealand and Japan) and 2500 spatial infrastructure data are included. Other useful features include a custom terrain feature, a world geographic coordinate system conversion feature, DXF-XML conversion as well as a 3D and 2D terrain editing feature.

  • Geographical Survey Institute Authorization (2000, #173): 50m mesh elevation (nationwide) / 2500 spatial infrastructure data (Tokyo / Osaka)
  • World geographic coordinate system conversion tool authorization: (#603, Planning and Coordination Division of the Geographical Survey Institute)

50m mesh altitude (nationwide) 2500 spatial data infrastructure(Tokyo/Osaka)


Efficient VR data creation assistance through the use of standard models/textures and an extensive download DB

  • In addition to the standard data including 3D models and textures, extensive downloads are available directly from the UC-win/RoadDB on the Internet. Useful editing and movement tools are available, allowing scaling up and down, movement, rotation, inclination and arrangement of models. Action setting offers generation and motion control of moving models.

Easy creation of a complicated road structure is available with high definition.
All sorts of lines such as roads, rivers, lakes or flight paths can be set up with parameters or free hand drawing and roads, tunnels, bridges, rivers or walking routes can be automatically created.

  • Tunnel and bridge sections are set by the definition of a horizontal road alignment (clothoid and spline supported) and a vertical alignment.

Real-Time Display of Large Scale Spaces
It's possible to create data from the size of a dice to a 20 kilometer road structure in the same space. Maximum size is 8000 cubic kilometers.
Smooth dynamic display is supported by performance settings and 3D trees compatible with dynamic LOD.




Various displays with the Visual Options Tool. Traffic simulation of road hazards is also available.

  • Control of time, weather and light is available in real time. With the artificial light function, expression of day and night, and shadow is also available.
    Traffic flow generation, based on traffic volume, car profiles and traffic lights, and road hazards, from disasters and accidents, can be simulated.

Real-time VR operation by simple operations.
Helps presenters with Before/After, scripting and manual driving.


  • It supports several driving modes (speed of car, lane changing, height of viewpoint, viewpoint switching in 8 directions) and dynamic movement of viewpoint (from other cars, up and down, turn head). Automatic flight and walk-through are available with the flight path setting (editing in the 3D display is supported). More advanced simulation can be performed with manual driving and support for a 3D cockpit and multi-monitors.
Page Top Page Top

UC-win/Road Main features

DesignSimulationInterface

Geographical features in the world
Digital map of Geospatial Information Authority is applied to a world map.
  • ・50m mesh(elevation)(Approved number:2000, #173)
    ・Format of 5m mesh(elevation)New!
Support for world geographic data
(Support for the import of CGIAR-CSI SRTM 90m mesh, world's elevation DB . The data of China and Australia is preinstalled as default.)

The geographical features are enhanced. Using the "CGIAR-CSI SRTM 90m Database" for all parts of the world, geographical features of China and Australia are installed in UC-win/Road, as well as 50m mesh geographical features, altitude data of Japanese Geographical Survey Institute and 50m mesh New Zealand.
example of geographical data: China

geographicalDB:CGIAR-CSI SRTM 90m Database:
http://srtm.csi.cgiar.org/
Supported area in UC-win/Road
(As of September 17 2010)
The terrain data (Wap file) where the customer lives is provided when they purchase the product. The following terrain data can be provided as well based on the request.
Default provided area(Green)
1st released area(Red)
2nd released area(Blue)
3rd released area(Purple)
The latest released area : Europe, North Africa, Middle East area

Road-Terrain Matching Process

Deal with terrain matching processing in addition to cutting and banking by road generation

Ground leveling process Bank / Cut No processing


Creation of river, road section
  • River creation is improved in UC-win/Road version 5 - just like with roads, planar and longitudinal linear alignment is now possible.
  • Sample river model

Transparency of Cross Sections
Transparency rates of parts are selectable in the cross section editor.
Transparency of a transparent panels and translucency of a sound insulation wall or balustrade can be expressed easily.



Improved cuttings and banks and rounding of a small stage
We have improved the setting method of cuttings and banks. It allows the setting of width, angle of slope and textures for each stage of the right side and the left side. The rounding can be set for the berm.

Edit window of road sections-Cutting tab Example of rounding


Enhanced intersection function
  • More intersection types including rotary and L type are now available for generation. Complicated flat crossing and road signs are supported through 3DS output editing. The improvement realizing for vehicles to run on the model at intersection was added.


Intersection editing function
The function to generate road surface texture semi-automatically. It reduces the work load of texture generation work of intersection.



Building editing tool

Users can create 3D building models in any shape they wish whether it is square, circle, free form, or a combination. It shows the front-back, right-left, height and size and texture of surface for both day and night.



Generating forests
This feature allows the establishment of up to three types of tree models (per session) and automatic generation of between several hundred and several thousand trees at predefined locations. Collective deletion is also available.


Point cloud data modeling
  • Included in Advanced license. Point cloud data-imported VR modeling is supported. It supports line displacement function.
    The effect of dot sequence correction The edit of center line dot sequence Shibuya crossing

3D text model
  • Generation and arrangement of 3D text on 3D space are available.

Improvement of fire and smoke visualizationVer.up
  • With this function, you can present various phenomena including fire, bonfires, stream from hot springs and smoke from chimneys. The visualization and movement of smoke and fire inside tunnels is significantly improved.
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
    Detail setting of the shape and particle Wildfire(fire and smokeE
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
    Stream from hot spring Spark of fire
LOD function
  • By lowering the resolution of smaller elements, the processing time can be reduced without badly affecting the quality of the visualization.
    画像をクリックすると大きな画像が表示されます。
    MD3 character, how to generate LOD 2nd stage(Original mesh, Side texture, front textureE

Video wall and video player
  • Animation video display including cylindrical screen can be reproduced as 3D object.
    Movie play on curve surface(Shibuya scramble crossingE

FBX 3D modelVer.up
  • In UC-win/Road, new file format was added. It supports EBX file which can be used for various models in high accuracy. Moreover Bone animation of the FBX format is supported.
画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
File format Version
Autodesk AutoCAD DXF (.dxf) Version 13 and earlier.
Collada DAE (.dae) Version 1.5 and earlier.
3D Studio 3DS (.3ds) All versions.
Alias OBJ (.obj) All versions.

IFC plug-inNew!
  • The terrain data in the file described in IFC format can be imported/exported into UC-win/Road as a terrain patch.
    Screen of UC-win/Road and exported result of IFC format.

Plugin for loading parking modelNew!

RoadDataViewer plug-inNew!
  • This is the plug-in which displays the list of information of object (building and tree), texture, intersection etc. in a tree format.
     ・RoadDataViewer plug-in
  •  ・Verification of unconnected road connection point
     ・Verification of buried model


Simulation
Context
You can save many settings as follows and the context setting is executed easily to make the setting more effective.
traffic flow settings / whole drawing option / Before/After function / State of view position and scenery view



Fake light / Shading
A simulated lighting feature is offered by alternating textures for day and night. For lighting effects, blending and overwriting are supported. Moving models such as cars can be alternated as well.


Improvement of lighting function and rain features.
  • The spot light and head light function allows the simulation of night time and lighting. For instance, you can use it for a signal lamp a window lamp in a building or the light of a vehicle.
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。

Audio systemVer.up
  • By employing OpenAL, a variety of surrounding sound, the car's sound (sound of engine tire, wind, tunnel reflection sound) are supported. Lowpass filter is supported. Squeal sound (slip sound) and sound reproduction of 4 different wheels are supported.
    画像をクリックすると大きな画像が表示されます。
    Engine sound, combination of sound source Reproduction of grass and soil/ asphalt

Special weather effect and illuminationVer.up
  • The function of rain and snow expression was strengthened. Function of fog, thunder, wiper and water splashing which can specify the execution area are added.
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
    water puddle road surface
    画像をクリックすると大きな画像が表示されます。
    wind thunder
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
    rain ripple road mirage
    画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
    windshield wiper(rainE windshield wiper(snowE
    画像をクリックすると大きな画像が表示されます。
    water splashing speed of wiper

3D stereo display
  • Passive method which outputs the image to multiple screens with parallax, and Active method which outputs to one screen from side to side using Quadro video tip, produced by NVIDIA are supported. Wide-screen can be available.
    画像をクリックすると大きな画像が表示されます。
    Left-eye Right-eye

Traffic Rules Setting
Traffic light and lane control are handled, enabling the realization of car light and traffic simulation at traffic lights.
Traffic rules for Japan, New Zealand, China and Korea are loaded by default and moreover new rules can be added freely.

Traffic connector
The virtual type which connects between moving nodes can be defined and the traffic movement can be set from edit window of plan view or main menu.

Vehicle configuration / way points
Configuration of driving routes, starting positions, running behind other vehicles (e.g. trains), sound configuration and railroad crossings, by setting action control points, is available.


Signal control / Road hazard traffic simulation
Traffic simulations based on vehicle performance are supported.
It is compatible with various traffic rules, signal control and traffic lane control, and car lights and signal expression in traffic simulation are available.



Traffic simulation function enhancements
Traffic simulation functions, such as vehicle grouping, path ratio setting for that group, the setting of vehicle retention at intersections, traffic flow on/off settings are enhanced.


S-PARAMICS
  • Importing of vehicle movement log. It corresponds to 3D simulation of S-PARAMICS by micro simulation player.

VISSIM New!
  • Visualization of traffic analysis reading the result of traffic analysis of VISSIM

Interaction function
  • The interference check on the traffic flow and self-vehicle course generated from various traffic analysis software's, such as VISSIM and S-PARAMICS.(within less than 200m)
Improvement of traffic simulation realityNew!
  • Improvement in lane keeping assistance algorithm

Manual driving
  • Support for manual driving as well as traffic flow based on vehicle performance by vehicle type.
    Steering controller(Handle, Pas pedal) is required to be purchased separately for manual driving.

Game controller and driving manipulation
  • Supports driving manipulation by a game controller.

Force feedbackNew!
  • Automatic vibration deriving from road material and road shape and constant vibration within the area is transferred to the controller.
    Oscillation region

Display of revolving wheels with rudder angle
With Vehicle Editor plug-in, displaying revolving wheels and the steering angle can be performed by defining the front and rear wheels.


Vehicle cockpit setting

Side mirrors, the rear-view mirror (rear view) and car navigation system (display any view) can be displayed in real time.3D cockpit model parts are selectable.
  • Profile by vehicle type
    Compact car / Mid-size car / Full-size car / SUV / Sports car / Scooter / Motorcycle / Truck / Bus / Trailer (total 10 models)
  • Compatible profile
    Number of gears and gear ratio (1-5), final reduction ratio, engine torque (number of revolutions), wheel radius, transmission efficiency, friction coefficient, braking force, minimum weight, maximum weight (applications to random driving cars), minimum radius of curvature, inter vehicle spacing, motorcycle function, design speed factor

画像をクリックすると大きな画像が表示されます。 画像をクリックすると大きな画像が表示されます。
画像をクリックすると大きな画像が表示されます。
画像をクリックすると大きな画像が表示されます。
View angle

Road attribute
  • Setting the difference of friction coefficient on road surface in every texture is available.
    The difference of friction coefficient

Constitution of vehicle movement model
  • The expression of more realistic movement is now available by implementing model of overall. Vehicle movements, engine and each transmission from engine to wheel.
    Setting of vehicle
    Relation of stopping distance and surface Illustration of understeer
Tunnel lighting function
  • Setting the color and strength of tunnel lighting is available. The effect is applied to the traffic vehicle going into tunnel and an adjunct of road.
    画像をクリックすると大きな画像が表示されます。
    Entrance of tunnel Cockpit of the vehicle is expressed
    in more realistic.
Improvement of scenario function
  • Editing is possible during a scenario.
    画像をクリックすると大きな画像が表示されます。

Improvement of walking simulation
  • Speed alteration while walking is available. Walking operation with mouse was added.

Movement of waking crowd New!
  • It's the function which the user can set an area of the 3D environment within which the pedestrians can walk. Visual reality is improved and the time required for arranging multiple numbers of pedestrians (crowd) is greatly reduced.
    Avoidance behavior of pedestrians Pathway

Tsunami simulationVer.up
  • Result of analysis by flood analysis software "xpswmm" can be visualized in UC-win/Road. The visualization improved and the level of devastation in buildings by tsunami can be visualized.

Navigation
Dividing movement mode and simple viewpoint operation clearly, support the viewpoint operation in a movement mode.
Tracking movement mode
Movement mode Possible viewpoint operation
Free movement Rotation, moving back and forth, horizontal and vertical movement, free flight, satellite movement, jump
Running, Flight, Driving Rotation, rotation on an axis of object, satellite movement
Walking Rotation, jump
Chasing Rotation centering around object, satellite movement


Replay option
  • Vehicles, a pedestrian, etc. are recorded and played some dozen times per second in real time. (Option in additional cost)
    Confirmation of accident during driving simulation from the outside of vehicle.
    Vehicle coordinate, roll, pitch, yaw, turn signal, brake lights etc.
    Pedestrian coordinate, movements, roll, pitch, yaw
    Traffic light lighting situation
    Context context in scenario live

Noise simulation New!
  • With placement of audio source and audience area on 3D・VR space, the acoustic extent is simulated. An acoustic pressure level at each sound receiving point on sound receiving surface is analyzed in consideration of influence of ground surface, structures, buildings etc. (Option in additional cost)
    Construction noise analysis Road noise analysis

Interface

Support for unicode(Japanese/English/Korean/Chinese/French/Italian)
  • Standard version is available in overseas. Chinese limited version corresponds with Chinese language interfaces and traffic rules.
    It is compatible with user interface (Japanese/English (NZ)/Korean/ French).
    All languages are available in spite of OS language. Ver.5.2 supports for Italian.

Full screen, simulation panel
  • The full screen display with hiding all menu and toolbar is available. The control panel which allows the customization of panel arrangement and command is added.

2D plane view display
  • The position information in the plane view can be displayed in real-time.

3D navigation(3D mouse)
  • The moving operation in 3D space can be performed sensuously by using 3D mouse such as "Space navigator". It can be used together with ordinary mouse.
VR-Studio(R)Plugin
Page Top Page Top

UC-win/Road Plugin

VR-Cloud(R)Ver.up  Registered trademark: No.2011-8512


VR-Cloud(R)¤ÇÂθ³¡ª
3D Digital City:Machu Picchu  Build Live Kobe2011 Kobe

VR-Cloud (R) is a consensus building solution which uses 3D and VR on a cloud server. With only internet access environment, even thin client would be able to operate the VR space by web browser.
Virtual reality can be provided as a service on network.

VR-Cloud(R) Standard
  • The performance of VR-Cloud Standard is more than 4 times better (compared to UC-win/Road for SaaS) owing to the implementation of a unique transmission technology. The simulation of walking and driving can now be experienced very smoothly.
    Driving simulation Walking simulation, display of avatar

VR-Cloud(R) Collaboration
The addition to the Standard Version of communication tools, such as the annotation and 3D bulletin board functions, means that we now have a VR Cloud System that makes advanced communication and use of VR between clients possible.
3D bulletin board function
  • Creating discussion among users
  • Display of comments by other users in the discussion and reply
  • Comments in the discussion is displayed as 3D icon on the location specified in VR space.
  • They can be saved in a different server. Servers can be synchronized amongst each other.
Annotation function
  • Making annotation of users with a simplified editor
  • Display and response of annotation by the other users.
  • Annotation is displayed on specified VR space location with 3D icon.
  • Saving in a different server and synchronizing between servers is possible.
3D icon of 3D bulletin board function and annotation function Edit screen of annotation function Discussion screen of 3D bulleting board function

VR-Cloud(R) Flash Version
Unlike UC-win/Road for SaaS, remote control of VR space using Adobe Flash Player on the web is possible, hence no need to install software to the client (However it is the more or less limited in terms of speed, latency, and features than the Standard or Collaboration version.).
FORUM8 received "the Special award of the 8th CSAJ Alliance Award" from Computer Software Association of JAPAN (CSAJ)! (posted '11.06.09)

SaaS type of 3D real-time simulation software "UC-win/Road for SaaS(Current name: VR-Cloud(R))" and SaaS type of civil design software "UC-1 for SaaS" received an award "the Special award of the 8th CSAJ Alliance Award" hosted by Computer Software Association of Japan (CSAJ).

The Ministry of Economy, Trade and Industry Cloud research business adoption! (posted '10.10.12)

As for "Agent service expenditure for Industrial technology research-and development (Next-generation high reliability, Energy-saving IT based technical development project)" (2010), "the service to use virtual 3D space supported by consensus building in cloud computing" was adopted.

Patent Pending We are currently applying patent for our technologies below.

  • a3S(Anything as a Service):Cloud transmission library (posted '11.01.04)
    Data transmission technology of 3DVR cloud, VR-Cloud(R)
      【No.】2010-290022
    an example of a3s system architecture
  • Input device for driving simulation: (posted '11.06.24)
    Technology that enables driving simulation using a keyboard.
      【No.】 2011-137288
  • Solution for obtaining stakeholder consensus on 3D virtual space (3D bulletin board function): (posted '11.06.24)
    Technology that creates, edits, shares etc. comments for discussion on 3DVR space.
      【No.】 2011-133352
<Reference Page>
【Up&Coming Vol.91 New Products Introduction】 a3S(Anything as a Service)

Micro simulation player Plug-in

Micro Simulation Player is the function to run various types of simulation animation which is depicted as 3D model movement. It is capable to record and play a traffic flow as a result of UC-win/Road and other traffic simulation.
Traffic simulation
Record/Play
Evacuation simulation
Analysis of traffic accident 4D Simulation(Construction management)
  • 3D animation function : It's possible to create various type of 3D model's animation based on the information of model's location. It enables to run several data at the same time.
  • Snap function for vehicle and pedestrians : It's capable to locate objects such as vehicle and pedestrian on the road and the lane, the pedestrian, the ground.
  • Controlling the existing objects : It's possible to control static objects such as traffic light.
  • Controlling drawing objects : Time, weather, light
  • Optimal integration with the functions of UC-win/Road : Traffic, script, camera mode
 <User case study> UC-win/Road Micro Simulation Player for Legion (posted '10.05.17)

OpenMicroSim site is open!
   XML Schema Open site for Open Micro Simulation Player  http://openmicrosim.org/
   Open Micro Sim is an open format developed and proposed in our company.

Point-cloud Plug-in  Real time VR supports 60,000,000 point cloud.

3D modeling by Point Cloud measured using the high accuracy GPS movement measurement device as a utilization case of 3D information in measurement and construction industries is paid attention.
Road cross section/ Road section editor
Road modeling
Point cloud data only Road model
Model of traffic intersection in Shibuya
  • A variety of editing function including creation of horizontal and vertical center line
  • Display of 3D point-cloud data to VR space
  • Conversion land and ocean bed into Tin, pasting of the image
  • Automatic color assignment for aerial photographs
  • Exporting to LandXML
  • Supported point-cloud number ・32bit: less than 16,000,000 ・64bit: more than 25,000,000

UC-win/Road for TsunamiVer.up

This is a dynamic 3D simulation of the tsunami analysis result by xpswmm. Tsunami expression function by UC-win/Road.
  • 3D animation function
  • Snap function of models
  • Control of existing object
  • Control of drawing effect on an object
  • Optimal integration with UC-win/Road function
<Lecture Report>
 <Simulation Movie>

OSCADY PRO Plug-in

OSCADY PRO is a software to analyze traffic for designing traffic signal and to optimize its phase. As a collaborative function of UC-win/Road, you can check the analysis result of OSCADY Pro in 3D VR space.
Intersection figure Signal phase Import maximum capacity and minimum delay
  • Import the results
  • Exchange the traffic profile
 About OSCADY PRO
  • OSCADY Pro allows automatic setting of signal phase and arrangement, and optimized signal capacity and congestion, and gradual and swift optimization of traffic signal. It's compliant to "Revised at Grade Intersection Plan and Design, the 3rd Basic volume, Japan Society of Traffic Engineers, July 2007." To optimize, it automatically set the phase, based on the signal phase and timing of signal changing cycle. Signal optimization tool detects optimized timing, based on 3 policies- decisive time cycle, aximum capacity and minimum delay. (Oscady developed by TRL : Transport Research Laboratory)

S-PARAMICS Plug-in

Virtual reality environment of UC-win/Road can be used to visualize landscapes, road designs and traffic as well as to check road conditions from the driver's viewpoint on our state-of-the-art Drive Simulator. This plug-in can be made for effective use of advanced traffic simulation.

Data exchange function
Due to the difference in data format for road networks in traffic simulation and in Virtual Reality, data conversion is required. This plug-in option is designed to minimize the work load by exchanging data.
(S-PARAMICS developer: SIAS limited. U.K.)
The roundabout imported from S-PARAMICS. The node with roundabout attribution and the transition of right section are expressed in UC-win/Road.

Sample
The 9th 3D VR Simulation Contest data, "Transfer VR simulation at Junjon Service Area in Korea, GTSM Inc. (Korea)" converted into S-PARAMICS data.

12d Model Plug-in

12d allows fast production in a wide variety of projects including mapping, site layout, road, rail and highway design, residential & land developments, and environmental impact studies.
(12d Model developed by 12d Solutions Pty Ltd, Australia)
Link of terrain data and road data Link of cross section data

Bidirectional conversion of terrain and road alignment
 New!
Import of road section New!
 Data link from UC-win/Road to 12d Model
  • Link of topography data : Topography data of UC-win/Road can be converted and exported to Tin file of 12d Ascii File Format.
  • Link of road data : In 12d Model, horizontal alignment data and vertical cross section data are regarded as input data, while cross section data is regarded as result data. Therefore, horizontal alignment data and the cross section data is converted and exported to 12d Model. In addition, users can define the conversion of the UC-win/Road 12d to the Alignment of the Super Alignment of the Ascil File Format.
 Data link from 12d Model to UC-win/Road
  • Link of terrain data : UC-win/Road regards terrain data as grid structure. To express more detailed terrain data, UC-win/Road can generate terrain patch/ In addition, TIM model of 12d Model terrain can be converted to UC-win/Road terrain data or terrain patch data.
  • Link of road data : There are two ways: Alignment and Super Alignment in 12d. Users can define the Alignment or the Super Alignment when converting the road data.

Noise Simulation Option

Width of general sound range is simulated by arranging a sound source and an audience area on 3D and VR space on UC-win/Road. In consideration of the influence of earth surface, a structure, a building, etc. the sound pressure level in each audience point on a audience side is analyzed. Noise simulation consists of preprocessor (input part), mainprocessor (analysis part) and postprocessor (Results view part). (Option in additional cost)
Setting of audio source Arrangement of audience area
Display of Contour figure Display of Contour line
Display of grid Display of sphere

Page Top Page Top

UC-win/Road Driving Sim

Driving Simulation Plug-in

With UC-win/Road and real car driving simulator with OEM-supplied, the driving simulation is much more realistic. Compared with a conventional driving simulator, a great improvement of the cost-performance is seen. Moreover, the biggest feature is that the user can freely use existing data or create a scenario specific to their needs.


Scenario Plug-inVer.up

In driving changing scene, various pre-fixed movements can be set to models. For example, when the car reaches a set position, pre-set model activity and various scenarios can be made, such as "Signal mast changes to red", "Car pushes in at the intersection", "traffic congestion occurs", "a man starts walking" By using these scenarios, the plug-in offers a real-vehicle-like driving simulation environment with realistic events.


ECO Drive Plug-inVer.up

This plug-in support the calculation of fuel consumption and carbon dioxide discharge generated in driving, and the making of graph based on the driving log in UC-win/Road. The Eco-Drive module is situated in the UC-win/Road tools menu with two separate functions. Firstly the user can activate an "Eco-Drive log output function" alternatively they can "Calculate the carbon footprint". The various parameters within the Eco-Drive evaluation formula area all capable of being altered by the user. All Eco-Drive data is automatically read within the Drive Log data file so that calculations can be re-created.

main features
  • Output and save of driving log, calculation of carbon dioxide
  • Each parameter value of calculation formula of carbon dioxide discharge can be arbitrarily changed.
  • Eco drive log can be saved as data file, and the calculation result can be replicated.
  • Graph generating function

Cluster option plug-in

UC-win/Road Cluster option allows more than 4 channel display per PC
and can synchronize multiple PCs and project images to multiple monitors.
The system will be ideal for simulators and conference rooms with 360-degrees cylindrical screen, and control room simulations.
Synchronization of flags, fire and smoke, vehicles and snow

main features
  • Easy operation :
    Easy set up and operation
  • Flexible system :
    No limitations to the number and configuration of clustered PCs
  • All functions of UC-win/Road :
    All functions of UC-win/Road can be used on clustered configurations
  • Improved performance :
    Improved performance on clustered system compared with single PC system
  • Multipurpose system :
    A variety of simulations are possible in this multipurpose system which has all elements synchronized

Communication Plug-in

This Plug-in allows communication with multi users by the use of UC-win/Road. Users can send chatting comment and surrounding information in UC-win/Road such as view position, direction and time through the Internet. These feature enables you to support joint designing and consensus building. In addition, it allows for network-based driving simulation.

User A
Explains the work with looking drawings and documents.
User B


main features
  • You can show your partner the same view that you are looking at.
  • It becomes easier with the displayed model to explain to the person who is not familiar with the data.

Motion Platform Plug-in

It allows you to link with the Motion Platform hardware OEMed by INNOSIMULATION,Inc , as a one of UC-win/Road Drive Simulation Options.


Replay Option New!

The data of vehicle and pedestrian can be recorded and played in real-time in a couple dozens times per second (It depends on the capability of computer)(Option sold separately).
  • Link with Scenario plug-in option: The record can be started and played when the event occurs.
  • Data management: Recorded data can be compressed by ZLib(Compression algorithm user for ZIP)
  • Link with UC-win/Road SDK: The data can be recorded and the replay function can be operated in SDK side.
→
The accident while driving simulation can be checked from outside of vehicle
Operation panel Toolbar
Vehicle Coordinate, roll, pitch, yaw, turn signal, brake lamp
Pedestrians Coordinate, behavior, roll, pitch, yaw
Traffic signal Lighting status
Context Context while performing scenarios
The behaviors to be replayed
Page Top Page Top

3D・VR Solution



Data linkage with IFC
The terrain data and design and analysis data such as structures and civil structures designed by BIM CAD are linked with UC-win/Road so that they can be checked in VR space.
UC-win/Road→IFC The example of BuildLiveTokyo 2010 utilizing IFC
Data Link with Road CAD
It is total integration system to allow you to design of civil engineering, such as road/land development, VR simulation, presentation by linking with Design CAD application and UC-win/Road.
UC-win/Road for Civil3D

UC-win/Road can link at object level with Next generation solution "Autodesk Civil3D" which brings a paradigm shift to civil engineering design process.


<Civil3D Main Function>
  • surface generation, rezoning design/land development design, alignment, linear calculation documents preparation, vertical alignment plan, cross section preparation, amount calculation, corridor, conduit line design, cross section quantity sheet, project management, shared data, electronic delivery compatible

UC-win/Road Data Exchange tool for Civil 3D
UC-win/Road InRoads plug-in

"InRoads", 3D land development /Road design system, can exchange data based on LandXML data reading/writing function. Horizontal cross section data is exchanged through the use of InRoads original XML format.
(Correspond to only reading from InRoads to UC-win/Road)


<Data Exchange Range>
  • Data read: newly road generation, road updating (alignment, vertical alignment, cross section)
  • ・Data write: objected road, terrain
UC-win/Road Data Exchange Tool for APS-Win

It has necessary function to examine the road alignment (road curve: clothoid curve), railway alignment (sine curve, cubic parabola) and can check designs and calculate coordinates. Moreover results can be output as an alignment diagram.

Data link with GIS applications
GIS application base on GIS Shape file import function and UC-win/Road
UC-win/Road Shape file plug-in

  • Shape file which is generally used in GIS can be imported
  • Linkage with system where file can be managed in Shape file format
  • Object: Terrain, road alignment, building model

UC-win/Road Shape file plug-in (Up&Coming 2007 Late fall issue)

UC-win/Road - GIS ViewUC-win/Road GIS Plug-in
  • Coordinate conversions for GIS format files
  • Import / Export of Image files
  • Import / Export of Vector files
  • Attribute table conversion
    -Import:
    • Shape file
    • MEM files ("50m mesh numerical value map" issued by the Geographical Survey Institute)
    • XML files (UC-win/Road data)
    • DXF files
    • slm, slp, sal, XML (1/25 000 and 1/2 500 numerical value map data issued by the Geographical Survey Institute)
    • TIFFs
    -Export
    • Shapefiles
    • DXF files
  • GIS format files to UC-win/Road conversion function
>

Data link with UC-1 Design Series
3D bar arrangement simulation
3D Bar Arrangement Simulation

Bar arrangement drawings made by UC-1 series can be imported for 3D bar arrangement simulation

Data link with road applications
By linking with "OSCADY PRO", traffic light design and "TRACKS", land usage and traffic modeling system, realizes VR simulation
OSCADY PRO   TRL(http://www.trl.co.uk/
  • Added road
      Position of road, number of lanes, automatic import of width and name, and setting road surface texture.
  • Intersection shape:
      With UC-win/Road's automatic intersection generation function, visualizes 3D shape and road surface marking.
  • Traffic flow:
       Allows automatic import of traffic capacity per lane, ratio of right turn, through traffic and left turn at intersection, and distribution of traffic vehicle.
  • Phase:
      By converting phase information of OSCADY PRO, automatically do the setting the traffic signal of UC-win/Road.

TRANSYT   TRL(http://www.trl.co.uk/
Specified format is provided from UC-win/Road. Vehicle position information is linked up with TRANSYT.
Aimsun   Spain TSS-Transport Simulation Systems(http://www.aimsun.com/
Public transportation, pedestrians/ vehicles are reproduced by dynamic traffic assignment technique.
VISSIM   PTV(http://www.ptvag.com/
The micro simulation system VISSIM and UC-win/Road are cooperated in mutual directions.
Road data of VISSIM Result in UC-win/Road
S-PARAMICS   SIAS(http://www.paramics.co.uk/
It's possible to visualize the result analyzed by S-PARAMICS.
UC-win/Road for TRACKS   Gabites Porter(http://www.gabites.co.nz/
Link with TRACKS by LAND XML file through NEX (road network editing program)
UC-win/Road for Sidra   SIDRA SOLUTIONS(http://www.sidrasolutions.com/
Plug-in for VR expressing the intersection designed by SIDRA by UC-win/Road.
Data link with analysis software
By linking with "EXODUS", evacuation analysis and flood analysis "xpswmm" realizes VR simulation
UC-win/Road for EXODUS

Data link of UC-win/Road and "EXODUS", evacuation analysis and "SMARTFIRE", fire analysis allows the viewing of the simulation result in 3D VR space.

UC-win/Road for xpswmm

UC-win/Road for xpswmm (Up&Coming 2009 Fall issue)

Allows 3D view of the result of "xpswmm", flood analysis and inundation analysis
Features:
  • Visualization of the terrain model(importing shape file)
  • Visualization of water level and pipe model
  • Analysis modeling of time-history
  • Large modeling with VR-Studio(R)
xpswmm UC-win/Road for xpswmm

UC-win/Road Option [Standard features ]
3D-Tree option 3D tress creation

  • The whole(shape/tree age)
  • Trunks/branches/leaves/flowers settings
    * 3-D trees are available in default Also available - leaves and branches swaying in the wind
AVI tool Option AVI movie capturing

  • Selecting CODECs
  • Specifying capture sizes
  • Specifying frame rates
  • Detail settings such as the generation of frames
Scripting Option Creating and editing scripts

  • Selecting and setting auto-executive scripts
  • Executing diverse external media files
MD3 editor Option MD3 human model editor

  • Setting movements of the upper and lower body
  • Selecting actions such as "running" or "jumping", scaling the models
  • Setting textures such as clothing
Vehicle Plugin

  • Registering and editing 3D vehicle models
    • Rotation axis, wheelbase
    • Trailer cab, pivot configurations

  • Displaying revolving wheels, steering angle
    • With vehicle plug-in, displaying revolving wheels and the steering angle is available by defining the front and rear wheels
Replacement Plugin

  • Grade intersection, 3DS output and replacement.
  • Expansion the type of intersection.
  • Complicated grade intersection, road surface is compatible with 3DS output editing.
  • Customized to enable driving at intersection in the model.
Road Obstruction Option

  • Lane control feature on the assumption of disasters and accidents
    • Arranging road obstacles (designation of lanes, positions, lengths, and detour start/end distances)
    • Displaying road obstacles (textures of depression, cracking, disruption and such)

      * "Road hazard, road construction regulation, VR simulation system model" Oncoming release
POV-Ray Option

  • Rendering function through the use of "POV-Ray"
    • UC-win/Road Object compatibility(Except for eruption, snow, clod, HUD)
    • Check by light action of radiosity is available.
    • Tracing level setting
    • Examination range setting
    • Shadow: hard/soft
    • Mist (mist, haze)(No mist, global mist, local mist, both mists)
    • Light source setting, Lights with light script, Vehicle type
  • "POV-Ray" image sample
LandXML Plugin

Street Map Plugin

  • Edit and division of Street Map
Page Top Page Top

Associated products

WEB Viewer


UC-win/Road Web ViewerInternet tool supporting Internet Explorer (IE)
The VR case studies for each project can be viewed with Web Viewer.
Free Sample Data is available!

UC-win/Road Web Viewer is a web software allowing the display of 3D VR data created by UC-win/Road on Internet Explorer (IE). 3D VR can be viewed and a variety of simulations can be performed on PC where UC-win/Road is not installed.

Data Download

Various Simulation
  • It allows the creation of 3D VR, create driving / flying / walking simulations, traffic flow generations, scripting, and change of viewpoints etc. If the steering wheel is connected, user can perform driving simulation.


3D Digital City Modeling
3D VR(Virtual Reality) models are created with UC-win/Road. These are presented in our company magazine, Up&Coming.
>> Up&Coming City and architecture blog

Experience on VR-Cloud(R)!Special Page
Operation and browsing on cloud are possible.

GRAND PRIX GRAND PRIX
「System for checking the position where equipments are installed」
 Japan Railway Construction, Transport and Technology Agency

vrcon.forum8.jp

GRAND PRIX GRAND PRIX
World Cup Award
「The Oasis」 Urban city Lab, Kanazawa University (Kanagawa University, Japan)

vdwc.forum8.co.jp
3D Digital City:Machu Picchu
3D Digital City:
Kimbell Art Museum
Build Live Kobe2011 in Kobe

UC-win/Road Educational VersionEducation software for creating VR
For students in elementary school, junior high school, high school(under 18 years-old)
Price:US$399
This software, "Education software for creating 3D Virtual Reality", is only for students under 18 years old. It has the basic functions of UC-win/Road, so you can create and drive towns and roads in 3D VR space with your own computer. If you have a steering wheel, you can experience manual driving as well. You can also register the data you created into the database created by GISWeb Systems of GEOMania and make it public. You can also download and try the data created by others. This is a useful simulation software for planning and building towns.

VR data server
Data browsing / Web operation

Open data
on the web

←→
Data downloading
Data uploading
UC-win/Road Educational Version
UC-win/Road Educational Version
Creation of the town / Real-time VR simulation


GIS Web database can be accessed
via "Tool" -> "GIS Download"
Popular with children!
UC-win/Road driving simulator

Product Configuration
  • UC-win/Road Advanced base(without additional options)
  • Same behavior as Trial version
  • Data compatibility with UC-win/Road is not supported
  • Operating as product by inputting serial code or web authentication
  • UC-win/Road DB is available during effective period of maintenance contract
  • Web registration of UC-win/Road data(Stop motions x 2, descriptions)
  • Data registered by users can be available
  • Web match-up mode

Users can also use the additional tools listed below to enhance the data creation and simulation (additional tools, sold separately). >> Price List

Additional Options
Modeling Tools
  • 3D Tree Option (3D tree Editor)
  • MD3 Character Option (3D human model editor)
Creation Tools
  • POV-Ray Option(ray tracing)
  • AVI(AVI movie capturing)Option
  • Scripting Option(Creating and editing scripts)
Professional Tools
  • Traffic Light Option
  • Road Obstruction Option
  • UC-win/Road data conversion tool
Separately Sold Hardware

  • Steering Wheel

VR-Drive(TM) This is the driving educational package for junior with advanced techniques. It allows the experience of driving in 3D VR environment, usual driving scenario, and the hazard events on roadway.

Hardware
  • VR-Drive software, Logitec steering system for game, PC with graphic card are required.

Customization
  • VR-Drive consists of 3D environment and the driving scenario designed with traffic specialist.
    The customization of 3D environment can be flexibly performed, and the specific driving can be generated as you specify.(Estimation is required separately)

Interactive driving scenario
  • The driving scenario under bad conditions (pedestrian, bicycle driver, left-turn, right-turn, road with poor visibility) are predefined in VR-Drive.
    The young driver can experience the realistic road with the driving scenario.

Driving skill report
  • The report is generated after the experience of each driving scenario so that the experienced driver will be able to give appropriate advise based on this report.


Eco drive report
  • The report of CO2 emission amount and the fuel consumption is created for each driving.
    The young driver can learn the preciousness of human life and the contribution for the environment.

Visual effect
  • The driving in different condition such as rain/snow and daytime/night time can be experienced.
    The setting of surrounding environment including wind, flood, fire, smoke is available.

UC-win/Road SDK(System Development Kit)API is provided to customize UC-win/Road.

This API allows you the flexibility to develop and customize options similar to that of a basic UC-win/Road plug-in.
In addition, the reading and writing of UC-win/Road data and user interface customization are available in real time.

Data edit/read/write
Terrain : Grid , Patch (TIN)
Aerial photograph : Reading and writing of aerial photograph
Road : Horizontal alignment, Vertical alignment, Cross section, Bridge zone, Tunnel zone, Section interpolation, Texture
Intersection : Stop point, Texture, The placement (an allotment) of the traffic light model
Traffic : Traffic volume, Setting of extinction / the out, Setting of a traffic profile / the vehicle group
Model : The placement of a model

Customization of user interface
  • Adding of menu and form(adding of dialogue)
  • Dedicated menu creation is available.
    Simple menu development allows the distribution of dedicated menu to clients

  • Several Input/output plug-in developments are available.
    Data linkage with our software is available in real time.
UC-win/Road Ver.3.02.21(SP1) / Delphi 2007

Sample Program

Program for traffic flow settings

It will add "Traffic Generator Set" to the tool menu. If you click it, it will add "arbitrary traffic volume point" at the middle of each road, and does the basic set-up. It also sets up the traffic flow starting point at the edge of roads.

< Ver.5.00.01 (Released on 10/12/20) Updated contents >
  1. Support for Delphi 2010
  2. Support for over writing of driving control value of traffic vehicle, sample plugin- is provided
  3. Support for the specification of UC-win/Road Ver.5
< Ver.5.00.02 (Released 11/05/02)  Updated contents
 1.Acquisition of shape information of 3S model of road generated from the input data of linear and cross-section.
 2.Creation of the screen of camera view, customization of property

< Ver.5.02.00 (Released 11/07/26)  Updated contents
 1.Support for the alignment of the custom object
 2.Customization of the initiation condition of scenario and event
 3.Interface of DS plug-in has been expanded (Acquisition of DS state, control of DS active steering handle)
 4.Sample program has been added.

UC-win/Road SDK(System Development Kit)"Embarcadero Delphi Bundle Version" has been released.
Press release page of Embarcadero Technologies http://edn.embarcadero.com/article/40277

Future Development
  • Simulation control : View point/model moving
  • Simulation information acquisition : Event, eye point information, and model position from UC-win/Road
  • Customization of functions : Free drawing of OpenGL control
  • Support for COM-API as the expanse of development environment
Driving Simulation
  • Log Output
    Possible to receive the physical quantity of the vehicle at the time of driving simulation.
  • Information of position and direction of vehicle
  • Position information of road and vehicle
  • User's driving operation amount
  • Vehicle's speed, acceleration, engine RPM, gear
  • Vehicle's attribution: Weight, dimension, gear ratio, engine turque, brake stress, frictional factor
Model real-time control
  • 3D models and characters are added. The real time control function is added as well.
User operation acquisition

Others
  • Supports show / hide each model, and acquire polygon information
Log monitor
(standard sample)

UC-win/Road Data Exchange Tool
The tool allows data format conversion such as XML conversion/editing of DXF landforms and SIMA data exchange and is a supplemental / calculation tool for line shapes and cross-sections.
Embankment edges 3D model Creation Tool
  • This is a tool to create conical 3D models of road embankments which is often found at the edges of bridges. Road embankment edges can be complicated due to various inclinations, but this tool allows you to create embankment edges easily as you imagine the shapes by defining each dimension.
Road Data Viewer
Civil engineering 3D model creation tool
GeoMap3D data exchange tool
DXF data exchange tool
3D model exchange tool
Horizontal alignment IP calculation tool
SIMA data exchange tool
Tunnel cross section calculation tool


Transportation Census VR Simulation Data Development Tool
(Under development)
  • Road traffic census information (CD version, traffic engineering research group) can be used as traffic volume and profile information in UC-win/Road.(on the right above) Traffic simulations for weekday, holiday, day and night, and rush hour can be set. Traffic profiles by vehicle types can also be assigned. Weight adjustment function is also supported.

UC-win/Road 3D Stereo View SystemPrice: Ask
Scheduled to be supported by the UC-win/Road Ver.4

Social demanding of 3D Stereo View is increasing against the background of the technical infrastructure of hardware.
UC-win/Road 3D Stereo View allows you to output the VR data by the UC-win/Road into the data in 3D stereo view data format.
It will be used for researches, developments and amusement, as well as VR creation, driving simulation through the 3D stereo view.
Support both methods: Polarizing Projection (Passive) using binocular parallax and Active.

Example of 3D Stereo View System Configuration

Example of Polarizing Projection (Passive Method)
  1. Set two projectors to overlay displays.
  2. Project through the polarizing filter.
  3. Set the distance between two eyes or the focal distance through the UC-win/Road Stereo Option
  4. Project on the silver screen and wear the polarizing glass, and you will be able to see the 3D stereo image.
1.
2.
3.
4.


Hardware Requirements
  • Polarizing Projection (Passive Method)
    -Silver Screen Projector (two units) / Projector rack / polarizing filters for projector (two pieces)
    -Polarizing filter Glass / 3D Video Card: Two output terminal (Two Video Card Configuration is recommended.)
  • Active Stereo Projection
    -Standard White Screen Stereo Projector (one unit) / synchronized emitter
    -Active Glass nVIDIA Quadro

3D Display Plug-in(under development) New!

True3Di 19inch monitor SDM-190M Redrover Japan Co.,Ltd.

It provides 3D work environment as well as many 3D applications.

Aspect ratio SXGA
Resolution 1280x1024
Active Display area(mm,typ) 376.32(H)*301.056(V)
Color number 16.7M
Response Time(ms) 5
Dimensions(WxHxD)mm 452x467x418
Input Signal(2ports) AnalogRGB,DVI
Weight(Kg,lbs) 30Kg,66.1lbs

Exhibited at FORUM8 Tokyo head office

Same contents (UC-win/Road)

UC-win/Road Presentation Version
Product delivery styleUseful presentation version is available!

With UC-win/Road, there is a presentation version (52,500 yen). VR features available are similar to UC-win/Road. A variety of visual option functions allows you to do various simulations. With delivery in AVI file, a screen view is recorded through the AVI option feature (84,000 yen) and, if necessary, it can be mixed with voice or music using Premier (Adobe) and such. When directly printing out other captured images, it is recommended that you do so in a higher resolution.(Example of maximum resolution: 4096x1536 pixels when dual screens are used)

UC-win/Road related books
 The introductory guide of the advanced graphic language
                       -OpenGL Ver.4&CUDA-
NEW
Introductory book for civil construction engineers to learn the graphics programming using OpenGL

This book is for the civil construction engineers with the experience of programming to learn the graphics programming and parallel programming. It explains the OpenGL programming using SDK(System Development Kit) of VR(UC-win/Road) and the advanced parallel graphic language including CUDA. This book consists of simple structure with the contents of programming, many flow charts. In addition, the many reference images are introduced in case studies.

■Author Assistant professor Kensuke Yasuhuku, Cyber media center, Osaka University)/ Hiromu Ito/ Takeyasu Okuma/ Pencreach Yoann(FORUM8-VR development groupE
■Date of issue November 16, 2011
■Price 3,480 yen(+TaxE
■Publisher FORUM8 Publishing

 Special supplements DVD
  • E-book version “Programming of OpenGL for civil engineers”
  • UC-win/Road Ver.6 trial version
  • Open GL Sample Program
  • UC-win/Road SDK Sample Program
  • CUDA Sample Program

 ■Introduction of contents

 Chapter 1  OpenGL
   1-1 VR and OpenGL 1-2 Development of OpenGL with Delphi
   1-3 Preparation of drawing and clear screen 1-4 Drawing of primitive figure
   1-5 Coordination system and geometric transform 1-6 Lighting and material
   1-7 Texture mapping 1-8 Shading language GLSL
 Chapter 2  SDK
   2-1 UC-win/Road SDK’ s structure 2-2 Introduction of SDK new function
   2-3 Rendering process 2-4 Examples of plug-in development
 Chapter 3  CUDA
   3-1 GPU computing by CUDA 3-2 Development environment of CUDA
   3-3 CUDA for beginners 3-4 Application program


"Programming for civil engineer" NEW
Utilization of SDK in VR structure analysis learning with Delphi

This is the introductory book for less-experienced civil engineers to learn programming with SDK(System Development Kit). The simulation using VR software, UC-win/Road has been marked in the laboratory of university or research institute. We will propose the utilization of solver for structural analysis.

This book includes the trial version where the sample data can be available. It consists of a variety of diagram
and images such as the contents of programming and flow chart to be simple to understand.

Beginner's course on programming for civil construction engineers
This topic is the series of our advertisement magazine, Up&Coming. The case studies of advanced development using programming with Delphi and SDK(System Development Kit) for less-experienced civil construction engineers are simply explained.

CD-ROM included
Delphi2010 trial version
FRAME(2D) SDK sample program
Multiframe automation sample program


Published date : November 19, 2010
Price : 3,087 Yen(Tax inclusive)
Publisher : Nikkei BP Inc.


Contents

Chapter 1 Delphi
  1. Why Delphi
  2. Delphi basics
  3. Source code structure and value
  4. Control statement and component
  5. File input/output and event
  6. Major components and GUI
  7. Delphi2010 features and future development
  8. Hot to use sample code
Chapter 2 Development of structural analysis
  1. Points of structural analysis programming
  2. Structural analysis(FRAME in plain)solver development
    SDK utilization for FRAME in plain
    How to use sample programs
  3. Multiframe, structural analysis automation development
Chapter3 Virtual reality development
  1. What is VR(UC-win/Road)?
  2. API and using plug-in option
  3. UC-win/Road configuration
  4. Sample code for exercising(1)~(11)
  5. Example of plug-in options and its application
    (1)3D CAD plug-in options
    (2)EXODUS plug-in options
    (3)xpswmm plug-in options
    (4)Application of Micro Simulation Player
  6. Advanced development cases
    (1)Development of driving simulator
    (2)Development of railway simulator
Chapter 4 User case study
  1. VR data exchange tool plug-in
    Associate Prof. Yoshihiro Kobayashi, Arizona State University
  2. "Collaborative system of Osaka City physical model and VR"
    Associate Prof. Tomohiro Fukuda, Osaka University
  3. "VR model automatic generation tool"
    Associate Prof. Kostas Terzidis, Harvard University Graduate School (plan)
  4. "Shibuya crossing pedestrian model and interactive devices"
    Mr. Taro Narahara, Graduate School of Design, Harvard University
  5. "Driving simulation- customization"
    FORUM 8 Product Users
  • At the end : Overview of VR-StudioTM SDK、Engineer's StudioTM SDK、ADF
  • Coffee Break : Utilization method of copy protection and hardware rock(HASP) is explained

"Construction engineering software series:
VR case studies for construction project」
(Chinese version)
NEW
"Educational material of UC-win/Road by Shenzhen Tsinghua Sware Software"
"Construction engineering software series : VR case studies for construction project" was issued in July 2010 by FORUM8's dealer in China, Shenzhen Tsinghua Sware Software.

In this book, it shows how to create the VR simulation project with UC-win/Road using the actual VR project and advanced use of UC-win/Road.

Contents

  1. Overview of UC-win/Road
  2. Introduction of overview of VR tool
  3. Case study of basic use-Urban simulation
  4. Architecture unit simulation
  5. Multi-level VR simulation
  6. VR of construction of underground continuous retaining wall
Created by VR group of Sware

"Manual for utilization of UC-win/Road" (Chinese version) NEW
"Introductory book of UC-win/Road"
Introductory book in Chinese version, learning 3D space creation with VR and VR simulation techniques

It is decided that "Manual for utilization of UC-win/Road" Chinese version will be issued by China Architectural Construction Publishing.
The operation of 3D virtual reality software, UC-win/Road and the data creation method are explained in detail. A variety of case studies in each area are introduced, this book will be effective for the beginners who learn 3D landscape creation and VR simulation techniques. It will be useful for not only the beginners but also the professionals who want to brush up their data creation level.
UC-win/Road Ver.3.4 Trial CD included
  • Published date : 2010(scheduled date)
  • Price : RMB88
  • Publisher : China Architectural Construction Publishing
  • Editorial supervisor : Prof. Ma Zhiliang, Tsinghua University, Dept. of Engineering
  • Original authors
    • Editorial supervisor : Shigenori Tanaka
    • Editorial adviser : Yuji Ito, Chikako Takei
    • Author : Kantaro Monobe, Hiroya Yoshida, Satoshi Ishida, Masayoshi Taniguchi, Yuki Torigata

Contents

  1. Introduction of UC-win/Road overview
  2. UC-win/Road Interface
  3. Terrain
  4. Road
  5. Ramp
  6. Intersection
  7. 3D Model
  8. Traffic Animation
  9. Presentation
  10. Simulation for reducing traffic jam
  11. Creation of barrier-free town
  12. Future of UC-win/Road

"VR Presentation Technique"
FORUM 8 planned to issue the book related in the VR presentation technique in collaboration with CAD&CG magazine, X-Knowledge, and "VR Presentation Technique" was issued. The articles were written by Associate professor, Tomohiro Fukuda, the department of Osaka university, Mr. Fumio Seki, Taisei Engineering, the case studies of VR was introduced and the VR modeling and the presentation techniques using UC-win/Road was explained. This book became the latest unique VR technical specialty journal. It consisted of a wealth of contents including the special article from architecture, Mr. Tadao Ando.

UC-win/Road Ver.3.4 Trial CD included
  • Special contributed article by Mr. Tadao Ando
  • VR presentation case studies
    Authors: Tomohiro Fukuda / Fumio Seki &Co.
Published date : November 19, 2008
Price : 3,990Yen(Tax inclusive)
Publisher : X-Knowledge Co., Ltd
160 pages full colored

Including various contents such as interviews and dialogues

"Utilization of virtual reality"
-Urban development using 3D VR -UC-win/Road Introduction
This is a simple introduction book which comment on from the summary of UC-win/Road
to how to create data and how to run a simulation.
UC-win/Road Ver.3.2 Trial CD included
Publisher : Kentsu Shibunsya publication
Price : 3,980 Yen(Tax inclusive)
Editorial supervisor : Prof. Shigenori Tanaka in Kansai University Faculty of Informatics

UC-win/Road Video Tutorial
Japanese / English / Chinese / Korean

Price : 31,500 Yen (Tax inclusive)

The visual lectures with movies and sounds show how to create data and use other methods.

2010/06/16
UC-win/Road Ver.4 Video Tutorial (Japanese/English) was released.

Page Top Page Top

History

History

■:Software  ■:Option
Upgrade History
UC-win/Road improvements over time.

2000.05
1.00.00 Release

2000.07
1.01.02 Switching from Japanese to English / lane changing.

2000.12
1.01.12
Editing function for elevation points.

2001.06
1.02.00
Shadow, rain, snow, wind.
Level crossings.
Custom terrain handling.
XML terrain loading.
On / off ramps.
Flight paths.
Satellite camera view.
Locating models along a road.
Street map extension.
Driving on the right side of the road.

2002.06
1.03.00
World geographic coordinate system.
Movable parts for 3D models.
Rivers.
Road Marking.
Power lines.
Flags.
Terrain transparency.
Before / After.
Joystick Control.

2003.06
1.05.00
Data merging.
Lakes.
Drag movement of models.
Measurement between models.
3D Tree Editing.
Creating AVI Files.

2003.09
1.06.00
2D view window.
Support for multiple monitors.

2004.06
2.00.00
Traffic generation.
Travel route.
Lighting effect textures.
Script functions.
MD3 characters.

2004.09
2.01.00
Forest generation.
Wheel base setting.
Pivot setting.

2005.05
3.00.00
Traffic lights plug-in.
Road obstacle plug-in.
Indicator and brake lights.


Ver.3.00 new features

2005.12
3.01.00
Drive simulation and cockpit.
L-shaped intersection /
roundabouts.
POV-Ray.
LandXML.


Ver.3.01 new features

2006.05
3.01.02 UC-win/Road for Civil 3D

2006.09
3.02.00
Support for French and Chinese (Formosan).
Vehicle grouping.
Vehicle appearance and disappearance.
Vehicle queues.
NZ terrain data loading.
Multi view display
Tracks plug-in.

2006.11
3.02.11
(SP1)
Level of detail LOD.
Savable view points.
Rear-view mirror, side mirror and car navigation in 3D cockpit.
Scale setting for 2D car navigation display.
3D display size setting.
Expanded dynamic control points commands.
Expanded script commands.

2007.07
3.03.00
Space Navigator 3D mouse
Support for advanced game controller settings
Support of default settings for bridge and tunnel cross sections
Improvement of Draft mode
Improvement of Performance function
Improvement of shadow expression
Separate settings for transitions in traffic lanes
Support for separate drawing of 2D and 3D trees
Responses to internationalization (UNICODE, traffic rules etc.)
Support for terrain creation corresponding to road definition
Support for creation of transparent road cross sections
Traffic simulation control as a new function


Ver.3.03 new features

2008.08
3.04.00
Advanced building editor
Full-screen view and simulation panel
Driving interaction, scenario creating
Drive simulator plug-in
Shape file plug-in

2009.02 ~ 2009.10
3.04.05
-
3.04.13
Scenario improvements
Wheel animation
Rudder angle display
UC-win/Road data DB
GIS plug-in


Ver.3.04.09 New Features

Ver.3.04.11 New Features

Ver.3.04.13 New Features

2009.11
4.00.00
lighting function
3D stereo display
berm rounding
context
World geographical data / traffic connector
plug-in integration


Ver.4.00.01 New Features

Ver.4.00.03 New Features

2009.10 ~ 2010.08
1.00.00 VR-Studio(R) release 1.00~1.02

2010.08
5.00.00
UC-win/Road for SaaS and remote access plug-in
Point-cloud plug-in
FBX file
Navigation function
Vehicle moving model
River creation and improved section setting
New sound system
Text model, script, scenario message
Video wall and video player
Drawing performance
Special weather and lighting

VR-Studio plug-in
Import function of S-PARAMICS vehicle movement log
Improved user interface
License and protect


Ver.5.00.00 New features

2011.01
5.00.03
It supports Korean, Chinese (Simplified, Traditional)
It supports import to VISSIM of micro simulation player. (VISSIM 5.30ANI file, produced by PTV in Germany)

Ver.5.00.03 New function
Click the image for a larger picture.


2011.05
5.20.00
NEW
Improvement of vehicle movement model
Italy version to be available
Tunnel lightning function
Revision of scenario function
Road attribute
Animation of steering handle
VISSIM to be supported
Improvement of getting on and off the vehicle

Noise analysis function
Replay option
Cluster option

Ver.5.20.00 New function
Click the image for a larger picture. Click the image for a larger picture.

    2011.12
6.00.02
NEW
EXODUS Plug-in
Replay Plug-in
Movement of walking crowd
Animation of FBX model
RoadDataViewer Plug-in

IFC Plug-in
12d Model Plug-in
Improvement of xpswmm Plug-in
Terrain 5m mesh support

Plugin for loading parking model
Improvement of smoke visualization
New weather visualization
Extended driving simulation


  Ver.6.00.00 New function

Page Top Page Top

UC-win/Road DB

UC-win/Road DB

VR Model Internet Database

Use the Internet with this database of 3D models, textures and section data.
Direct downloading from the product is available.
* Free of Charge with maintenance and support products
Passenger vehicle having headlight, businessman model, tree textures have been added.

Number of registrations (2011.03.24):
*3D models: 3191 ; textures: 3697 ; section : 66 ; sample data : 55

UC-win/Road DB Download Ranking (January-June 2009) (posted on 02 July, 2009)
PDF 3D Model Data for UC-win/Road Users (2008.07.23) (54 page PDF, 23 200KB)

*VR Model DB
*3D 2D Trees
3D tree
leaves / bark / flowers
2D tree
tall evergreen trees / evergreen trees / evergreen shrubs / tall deciduous trees / deciduous trees / deciduous shrubs / tall flowering trees / flowering trees / flowering shrubs / house plants
*MD3 character human models
characters / animals / humans
*Vehicles / Equipment / Running models
Road vehicles
passenger cars / trucks / trailers / cabs / buses and taxis / bicycles / motorcycles / special vehicles
3D cockpit
Railway vehicle
High speed trains / ordinary trains / monorails
Airports / harbors / river facilities
port facilities / harbor signal equipment / rivers / flood control facilities
aviation / marine vessel, construction heavy duty equipment, temporary equipment
*Building / Facility / Structure model
Building / House / Store / Steel tower
office building (super high-rise) / (med to low-rise) / building (low-rise) / condominium apartment / general home / store / market / industrial facility/public facility / transmission tower
railroad / road structure
bridge superstructure / bridge substructure / road structure / gate pier / pedestrian bridge / traffic sign pole / marking
railroad / road facility
bridge superstructure / sign / alarm equipment / station / street light / others / road regulatory equipment / road accident
park facility
playground equipment / building / others
Others: sign / traffic control / disaster / others
*Road / Traffic / Traffic sign texture
paved road / railroad surface
pavement surface / railroad surface / others
banking / cut
planting / concrete block / concrete blasting / others
guardrail / curb / footpath
guardrail / curb / footpath
bridges: truss / beam bridge, tunnel, intersection
traffic sign
indication sign / regulatory sign / guide sign / warning sign / auxiliary sign / railroad sign / Korean sign / Chinese sing / U.S.A. sign / New Zealand sign / French sign / Malaysian sign / U.K. sign
marking
indication marking / Regulatory marking / others / Korean road marking / Chinese road marking
building (mural painting)
background
super high-rise building group / mid to low building group/ low-rise building group/ forest / fence / others
river, cockpit, sky, flag, terrain
water surface, others

Model

By using abundant standard models, data generation can be effectively performed, allowing use of the model editing tool and action settings of the models through easy operations. The UC-1 design series can be loaded and the structure models designed using UC-win and import textured 3DS-format models generated with other 3-D tools.
It exports from UC-win/FRAME(3D),RC substructure design calculation,UC-1 Series


3D Tree

3-D tree data exclusively prepared for UC-win/Road. Diverse features such as leaves and branches swaying in the wind, growth simulation, and such are available.


MD3 Character

PDF About MD3 Characters (making way from motion captures) (03/03/2009)
(16pages/PDF/ 813KB/Japanese version only)

Sample Movie


Texture

Excellent default textures of slopes, excavations, road surfaces, pavements, walls and such are available. Sky and landforms can be mapped in default, and many special textures such as trees and signs can be arranged with their dedicated commands. The cockpit while cruising can be used as a texture.


Section

Textures such as a cross section form, a road surface, a pavement are available as it is.


Example

UC-win/Road VR data download (supports for world heritage)


Construction machinery
For the 3-D models of heavy machinery, over 100 types of construction machines from Hitachi Construction Machinery Co., Ltd. are supported as moving models.
* Please refer to the CG data license agreement for the use of the 3-D models of the heavy machinery.
The copyright is reserved by Hitachi Construction Machinery Co., Ltd.

Disaster/Regulations
It supports model/texture for road hazard simulation. (Date provided by Road Management Technology Center)

*This database is provided having permission from Road Management Technology Center.

Construction Methods
It supports textures for construction methods.(Data provided by HIROSE&Co., Ltd)
*HIROSE&Co., Ltd has the copyrights of texture (photo image)

Air photograph(Digital orthophotos)

UC-win/Road digital map
  • Japan.map (50m mesh National Edition elevation)of UC-win/Road format、Tokyo.map、Osaka.map(Tokyo, Osaka district 2500 space data base) are offered at the same time.
  • This numeric map is composed of particular format of UC-win/Road, and its file size is compressed severely.

  • Reference : Digital map・data content detail

Satellite image pasting Air photograph

3D building model for UC-win/Road
  • 『Terrain Model』+『Solid Model』 data which make 6km2・9km2 1 lot.
  • XML(UC-win/Road topographic format)/offer by DXF form
  • Service area: Main area of Kanto, Tyubu, Kansai and a city designated by ordinance(About 10,000km2)
    3D building data/topographic data original data price: 100,000 yen / km2
    Fabrication for UC-win/Road 3D building data 150,000 yen / km2
    (Reduction of polygon, layers separated(For texture), elimination of feature such as unnecessary trees.)
    Sales unit: *1 mesh: About 1km2 9km2(3rd mesh)、 6km2(3rd mesh)
UC-win/Road read screen UC-win/Road 3DVR expressed image
Page Top Page Top

Product operation environment
3D data compatible format
  • 3DStudio Object *.3ds
    The Win series products such as UC-win/RC and FRAME (2D) have been made compatible with 3DS model creation one by one.
    Refer to : 3D software list (Japanese)

Product environment(required system)
  • Operating System
    • Microsoft Windows NT 4.0 (service pack3 or later)
    • Microsoft Windows 2000
    • Microsoft Windows XP
    • Microsoft Vista
    • Microsoft Windows7
  • Computer
    • PC/AT100% or compatible system

  • System requirements
    • Requirement Recommendation
      OS Windows XP 32bit Windows 64bit
      CPU Intel Dual Core more than 2.0GHz
      AMD Athlon(TM) II X2 2.0 GHz
      Intel Core i5/i7 more than 2 cores, more than 2.8GHz
      AMD Phenom(TM) II more than X2、more than 2.8GHz
      Memory 2GB 8GB
      Hard disk 5GB * 1 10GB * 1
      Graphic card nVidia 256MB
      OpenGL2.1
      nVidia 512MB
      OpenGL2.1
      Display 1024Ž×768 or greater, 32 bit colors
      * 2
      1280Ž×1024 or greater, 32 bit colors
      * 2
      Others DVD-ROM drive DVD-ROM drive, sound board

      * 1
      The required free space for installment of the product including the terrain data(in case of suggested system), sample data is described.
      In addition the free space for saving the downloaded model/texture data from the created landscape data and special data, the recorded AVI file is required to use this product.

      * 2
      Please use the default setting for window design and the font size.
      More than 20 inch of display is suggested.

  • Traffic simulation system requirements

    • Requirement Recommendation
      OS Windows XP 32bit Windows 64bit
      CPU Intel Pentium 4(3GHz) More than Intel Core i7 4 cores, more than 3.06GHz
      More than AMD Phenom(TM) II X4、more than 3.0GHz
      Memory More than 2GB More than 8GB
      Hard Disk More than 5GB※1 More than 10GB ※1
      Video card More than nVIDIA 512MB、OpenGL2.1 More than nVidia GTX 1GB、More than OpenGL2.1
      Display More than 1024Ž×768, 32bit color ※2 More than 1280Ž×1024 pixel , 32bit color ※2

      An extra cost option A Steering controller(a steering wheel, an accelerator pedal) is required to manual drive simulation on UC-win/Road

      UC-win/Road Drive Simulator Product Information Page

UC-win/Road cluster server machine system environment
UC-win/Road cluster plug-in, option server machine recommendation

Requirement Recommendation
OS Windows XP 32bit Windows 64bit
CPU Intel Pentium 4(3GHz) More than Intel i7 4 Core, More than 3.3GHz
Memory More than 2GB More than 8GB
Hard Disk More than 5GB ※1 More than 10GB ※1
Video card More than nVIDIA 512MB、OpenGL2.1 More than nVidia GTX 1GB, More than OpenGL2.1
Display More than 1024Ž×768、32 bit color ※2 More than 1280Ž×1024 pixel、32 bit color ※2

Benchmark Test Result
"Comparison list of working hours and items"(investigated by FORUM 8) (posted on February 19, 2009)
Page Top Page Top

Case studies in Advanced project


These are the special topic carried as a series, collaborated with the magazine
"Bridge and city PROJECT".

VR-SYMPO

The articles of the 9th UC-win/Road Conference, the 1st International VR Symposium, "Trend of information in construction industry", and SIGGRAPH2007 posted on the monthly magazine "Bridge and City project" were put with the acknowledgment of the publishers.

Analysis Technology

Introducing a series of special features in a cooperative project between magazine "Bridge and Urban Project" and FORUM8.
The latest examples of UC-win/Road application are introduced in monthly magazine "Bridge and Urban Project" (published by the Bridge Editorial Committee) in the series "Cases and Effects of Analysis Technology Applications such as 3D Analysis, Dynamic Analysis and Nonlinear Analysis of Civil Engineering Structures".
Page Top Page Top

VR Symposium


International academic group World16 by 3D・VR construction and construction researchers.
Research results presentation symposium in 2010

The 4th International VR Symposium where the research development related to VR will be presented. It will be held one day before the 3D・VR contest, and the researchers of leading universities in and outside of the country are invited for the purpose of announcing, discussing and utilizing the excellent researches, technologies and ideas. The tentative plan of VR application by UC-win/Road and VR- Studio(R)will be examined at this symposium through the study results of each researcher.

▼Seminar report
Page Top Page Top

UC-win/Road News



AWARD
SOFTWARE PRODUCT OF THE YEAR! Awarded in "Social/life category / public category"!

UC-win/Road was awarded the Software Product of the Year, 2002, by SOFTIC (Software Information Center). This award system rewards outstanding software products sold during the year under the sponsorship of the Ministry of Economy, Trade and Industry.
http://www.softic.or.jp
ソフトウェア・プロダクト・オブ・ザ・イヤー2002受賞!

Awarded with "Outstanding Technology Award" at the Construction Technology Expo, Kinki, 2003!

At the "Construction Technology Expo, Kinki, 2003" (hosted by the Land, Infrastructure and Transportation Ministry) held on November 27 and 28 in 2003, where its thesis was announced at an exhibition booth, UC-win/Road received the "Outstanding Technology Award". 350 new technologies were exhibited at the expo and five of them were selected for awards. We believe that the superior VR (Virtual Reality) features and examples of practical use of VR data in a wide range of fields were highly regarded.

National Land Construction Fair 2004, awarded "excellent booth prize"!

This event was held on October 1-2, 2004, organized by planning committee of "See, listen, touch, National land construction fair 2004 " with Chugoku Regional Construction Technology Development Congress, Japan Construction Engineer's Association, Chugoku Regional Development Bureau. FORUM 8 booth received the excellent booth award.

Construction Technology EXPO 2005 Kinki , awarded "best booth prize"!

This event was held on July 15-16, 2005. FORUM 8 received the "best booth award" voted by the 145 exhibitor groups and the visitors.

Cloud service of FORUM8 won the Special award at the 8th CSAJ Alliance Award ceremony!Award winning product: UC-win/Road for SaaS(Now, VR-Cloud(TM))!

UC-win/Road for SaaS (Current name is VR-Cloud(TM)" won "the Special award" at "the 8th CSAJ Alliance Award ceremony"(sponsored by the Computer Software Association of Japan (CSAJ)) held on June 8, 2011.
Software product of the year 2002
"Social life category / public category"
Construction Technology Expo, Kinki, 2003
Outstanding Technology Award "IT/Robot field technology"

NETIS
Ministry of Land, Infrastructure and Transport
NETIS registration
New Technology Information System
New Technology Name : UC-win/Road
NETIS registration number : CB-040092
Utility business classification : New technology for semi-general constructions(its efficacy to be assessed)
The utility business classification of UC-win/Road was determined to be a new technology and registered by NETIS (New Technology Information System) managed by the Land, Infrastructure and Transportation Ministry, on March 31, 2005. UC-win/Road has numerous achievements in the Ministry's direct projects and was therefore categorized as "new technology for semi-general constructions". We will continue to propose the use of VR in public projects.

  • * NETIS:
    New technology information supply system has been conducted by the Land, Infrastructure and Transportation Ministry since 1998. It has been opened since 2001, and there are about 4,000 new technology entries registered now.
    http://www.kangi.ktr.mlit.go.jp/netis/netishome.asp

Featured TV News Shows
VR simulation has received much attention

Featured TV news shows (UC-win/Road simulation)

2001/06/03 SUN-TV News (noon) Kobe Nishi-Suma Machizukuri Conference
2001/07/26 NHK Tokai Local News (noon, evening)
Multimedia VR Messe Gifu 2001 (at our booth)
2001/12/06 SUN-TV News Hyougo IT Business Fair (at our booth)
2001/12/11 NHK Kinki Local News (night)
INTERMEDIA FORUM 2001 (at our booth)
2002/01/27 SUN-TV News (evening) Kobe Nishi-Suma Machizukuri Conference
2002/02/19 SUN-TV (News Island, feature story) Kobe Nishi-Suma
Machizukuri Conference (caption "Created by Forum8" )
2002/08/20 Cable Television Kani (Land, Infrastructure and Transportation Ministry, "Douro Fureai Kengakukai")
2002/11/13 Tokai Television News (at our booth at Multimedia VR Messe Gifu)
2003/07/24 NHK Tokai, Noon News (IT CITY MESSE in GIFU 2003)
2006/03/25 TV Tokyo Shutsubotsu! Admachikku Tengoku(as a task of a group in Ikebukuro)
2009/06/18 NHK WORLD (Automotive Engineering Exposition)
2009/07/30 FNN News (Information of Ohashi Junction for the press)
2010/12/12 TBS Cutting-edge IT information SHOW revolution TV (UC-win/Road drive simulator)
2011/03/20 CBC/TBS Karada no Kimochi (UC-win/Road drive simulator)
Event scene Road day in Shinjuku on August 7, 2009 Introduction of "Advanced Drive Simulator" on December 12, 2011 TBS Revolution TV Driving simulation under noise in ear on March 20, 2011 CBC/TBS Karada no Kimochi

DigInfo
The movie of FORUM 8 was posted on the Internet news, DigInfo News.

"3D VR for cloud computing environment -UC-win/Road for SaaS"

"3D VR for cloud computing environment -UC-win/Road for SaaS" was posted on "Cloud computing EXPO" (held in May 12-14, 2010)movie news(DigInfo News).

Japanese : DigInfo http://www.diginfo.tv/2010/05/27/10-0070-r-jp.php
YouTube http://www.youtube.com/watch?v=389nmjnciac
English : DigInfo http://www.diginfo.tv/2010/05/27/10-0070-r-en.php
YouTube http://www.youtube.com/watch?v=4-qm9Tw-c38

"UC-win/Road experience simulator(6 axis motion SUBARU type)"

UC-win/Road experience simulator in "UC-win/Road Conference"(held on May 20, 2009) was posted.

YouTube : http://www.youtube.com/watch?gl=JP&hl=ja&v=6GN89LCLXPg

The 10th UC-win/Road Conference

FORUM8 News 【Ieiri laboratory version】
FORUM 8 New [Ieiri laboratory version] written by "Construction IT journalist" Ryuta Ieiri, who is seeking the growth strategy of construction industry using IT. The latest news of UC-win/Road, the review of events, and the FORUM 8 news are focused.
New registration for mailing service


  • "The virtual image and reality of Ohashi junction are integrated!" Vol.1 (issued on April 30 2010)
    • The virtual image and reality of metropolitan expressway, Ohashi junction are integrated!
    • Experience of reverse driving in expressway can be available! Highway Driving Simulator has been delivered.
    • FORUM 8 started to tweet the new information on Twitter!

  • "UC-win/Road support for Cloud!" Vol.2 (issued on June 1 2010)
    • Can we play "Escaping " game VR version? "UC-win/Road for SaaS" gains much popularity.
    • Analyze with BIM! Supports for 3D model creation, analysis support, and report generation.
    • Virtual and reality are integrated! The development of autonomous mobile robot for office is accelerated.

  • "The progress of booth design for IVR exhibition is opened in VR" Vol.3 (issued on June 23 2010)
    • Present for the participant! -from cloud to driving simulator-
    • From layout of exhibits to the flow of a crowd of people! The booth designing progress is opened with VR.
    • BIM in Japan is competed on simulation! Let's think of international development in construction industry.

  • "The booth designed with VR becomes the reality!" Vol.4 (issued on July 6 2010)
    • 500 people visited per day! FORUM 8 booth attracted attention.
    • Converts the point-cloud into 3D model! 3D/VR engineering service started.
    • This is also valued! Model creation service with 3D printer started.

  • "Exact match to the experiment result of seismic board in actual size!" Vol.5 (issued on July 21 2010)
    • Seismic force more than gravity force! The world largest seismic board "E-Defence"
    • "Engineer's Studio" allowed the reproduction of complex non-linear behavior.
    • Accuracy gave a shock to the judges! Both of the displacement wave shape and maximum value matched to the experimental result.

  • "Structural analysis support for cloud!" Vol.7 (issued on September 7 2010)
    • Woeful Chinese transportation condition! Unexpected request of UC/win-Road from Tianjin University
    • It's helpful for subway construction! Building EXODUS's success in Shanghai/Tongji University

  • "Surprisingly, even adults were surprised at VR!" Vol.8 (issued on October 5 2010)
    • Even adults were surprised at VR! Exhibit to Tokyo game show 2010
    • For Forum 8 users, please join as well! BIM application survey continues until October 6.

  • "Surprisingly, VR are working under cloud! It's cooperated with BIM and point cloud" Vol.9 (issued on October 19 2010)
    • Adopted by the Ministry of Economy, Trade and Industry! Proposal of technology research and development for cloud of Forum 8
    • like real town! Using point cloud of 3D laser scanner in UC-win/Road
    • Fighting by simulation! BIM showed the ability in Virtual Design Competition

  • "3 straight days! Design festival's promise" Vol.10 (issued on November 4 2010)
    • [Day1]11/17(Wed) 10:00~17:30 "4th Design conference"
    • [Day2]11/18(Thu) 10:30~19:00 "4th International VR symposium"/[11th UC-win/Road Conference]
    • [Day3] 11/19(Fri) 13:00~17:35 "9th 3D・VR simulation contest"

  • "Being able to make SDK easily! Civil construction engineering book for beginners came on" Vol.11 (issued on December 8 2010)
    • Play of players is reproduced as it is! 3D・VR simulation contest
    • Let's use SDK! "Programming book for beginners of civil construction engineering" was published.
    • CPD is enriched! Holding of seminar program from December to Jun was decided.

  • "The prize-winning works of 3D and VR contest appeared in YouTube" Vol.12 (issued on December 21, 2010)
    • 3D・VR simulation contest Prize-winning works can be watched on YouTube !
    • By using BIM, steel processing drawing can be created smoothly ! Surprised at "Allplan" experience seminar
    • It was surprised that "UC-1" series etc. began a cooperation with BIM.

  • "Lighter feel than expected ! We tried the software related to SaaS" Vol.13 (issued on February 1, 2011)
    • Why ! News related to Saas occurs one after another on homepage of Forum8
    • Lighter feel than expected ! We tried "UC-1 for SaaS FRAME-RC cross section"
    • You can experience as well ! Applying in SaaS Technology

  • "The relationship of 3D scanner and Algorithmic design" Vol.14 (issued on February 15, 2011)
    • Unique exhibition on cloud exhibition ! VR of F8, civil engineering design, supercomputing service
    • The persons concerned Virtual BIM competition gathered ! A festival of Algorithmic design
    • A large-sized printer is also got. Point bank of forum8.

  • "Sales management is also on Cloud ! UC-1 for SaaS evolves again." Vol.15 (issued on March 1, 2011)
    • Launch into huge market ! The China standard version appears on "UC-1 RC cross section calculation"
    • Sales management is also on Cloud ! An office work function is carried on "UC-1 for SaaS"
    • New magazine ! The forum 8 backups at the Web magazine of civil engineering and a construction.

  • "Huge tsunami is predicted ! Reduce disaster by VR." Vol.16 (issued on March 29, 2011)
    • Inexperienced tsunami is visualized ! Tsunami Numerical support service
    • A whole country is modeled ! VR-Studio Ver.1.03 has released
    • "Industry Museum" of VR ! Experience Corner Exhibition of head office of Forum 8

  • "15 trillion calculations per second times ! You can use super computer" Vol.17 (issued on April 5, 2011)
    • "Kyosoku" in the future ! FORUM8・super computer cloud Kobe laboratory is established.
    • Support by software ! A free rental license is published to a earthquake affected area user.
    • Going in and out are also checked ! A parking lot drawing system is released.

  • "Don't overlook a design error ! Structural Design Verification Support System-A appears." Vol.18 (issued on April 19 2011)
    • Don't overlook a design error ! Structural Design Verification Support System-A was released.
    • It also corresponds to full-scale dynamic earthquake-proof collation ! The subcontract service start of a design check .
    • An old model is also OK. All registered users are provided with an beforehand urgent earthquake warning.

Ieiri laboratory official blog(Japanese only) http://www.ieiri-labo.jp/

Construction IT world
A lot of hot news of forum 8 are introduced in the special medium "construction IT world" which disseminates the information on construction IT speedily, positively and pleasantly by Mr. Ryuta Ieiri.
Mr.Ryuta Ieiri's official web site "Construction IT world"http://www.ieiri-lab.jp/


The report about awarded works of "9th 3D ・VR simulation contest" were published in Nikkei Business Publications, Inc. Kenprattu Construction IT, "Ieiri Construction IT Labo".

  • Osaka without Highway bridge ! First prize of virtual reality contest (November 26, 2010)
    Featured information for construction IT of this time ~Forum8 "9th VR simulation contest"~
    Osaka without Koka bridge ! First prize of virtual reality contest
    Ieiri focused on this ! ~Reproduced the movement of softball players is reproduced beautifully.~
Page Top Page Top

UC-win/Road Drive Simulator

UC-win/Road Drive Simulator
  • 4 wheels vehicle drive simulator packaging system

It allows you to create several driving situations and re-create it under complete control.

Recently Drive Simulator is widely used for vehicle system development or interaction research among drivers, vehicles, road and traffic, on ITS traffic system research.
  • Free style of creation of 3D driving environment with UC-win/Road
  • Standard plug-in included
  • Standard VR data included, support for scenario customization
  • Various environment representation with visual option tools
  • Reasonable pricing mass OEM production
  • Support for advanced simulation with customization

UC-win/Road Experience Simulator
  • 6 axis motion unit/Subaru Driving Simulator

Based on Subaru automobile's technologies, the simulator body adopted 6 electric axis motion units (patented) developed by merging flight simulation technologies from aerospace division of Fuji Heavy Industries and automobile technologies from Subaru automobile. The use of actual car steering mechanism gives you a sense of realism whilst driving.
UC-win/Road Experience Simulator allows you to simulate driving environments in accordance with the rapidly improved car safety technology of ITS technologies (crash avoidance, decreased impact, etc.)


UC-win/Road Highway Driving Simulator NEW
  • Potential hazards on highway can be reproduced by the driving simulator

FORUM 8 has installed custom Highway Driving Simulator to Convention on Social Contribution of Highway on March 1st, 2010. From now the simulator will be used at events and exhibitions on highway and its facility.
This simulator has been developed the system based on virtual reality, UC-win/Road. It allows the driving simulation experience of the hazardous event in highway according to the scenarios.
3 scenario combined with 19 events can be set and the simulator outputs tabulated driving diagnosis according to the driving log.
The hardware of the simulator employs 6 DOF motion platform with real car parts option made by SUBARU.
  • Experiencing 19 hazardous events on highways and its facilities
  • Setting items of experience driving
  • Hard : 6 axis motion SUBARU driving simulator


UC-win/Road Safety Driving Simulator NEW
  • Driving simulator for driving school according to certification standards for driving simulator(Uncertified)

Based on the certification standards for driving simulators
  1. Hazard perception
  2. Night-time driving
  3. Sudden braking
  4. Driving on the highway
  5. Location-specific conditions
  6. Driving in bad condition

Optional scenarios
  1. Identifying violations
  2. Night-time visibility

System configuration
  • PC for central control
  • PCs for the driving simulators
  • Printer
* All units are connected on a network

Diagnosis / Data collection program
  • Diagnosis software
  • Data collection software
Page Top Page Top

●UC-win/Road Auto Parking System  NEW
  UC-win/Road for RoboCar(R) Ver.2 AURELO

UC-win/Road for RoboCar(R) Auto parking demonstration (posted '11.09.14E YouTube

Autonomous driving by a reduced model of a car (RoboCar(R)). Driving and traffic simulation linking a real space and 3DVR is possible by UC-win/Road.
AURELO (Augmented Reality Localization System) is the system for tracking the information of the absolute position and the direction.
Several markers can be tracked at the same time by AURELO. Each marker shows the same boundary (black square), and the markers are recognized based on the patterns inside the black square. In the used AR tool, only the transform matrix of each marker which is relative to camera reference frame can be recognized. As the result, the information of the real RoboCar(R) absolute position can be tracked by two markers using a camera on the top of RoboCar(R) course.
RoboCar(R)
▲Localization of 2 markers
using AURELO in 3D
▲AURELO upper view

UC-win/Road Super-jumbo DS system
  • 6 axis +Yaw・X table and the entire circumference 8 projection ・ cluster composition outline

Research-based 8DOF road safety simulation system composed of 6DOF, Yaw-Table, Vibration, X-Table, cabin, multichannel projection system, sound system, supply system and the other subsystems.

1. Motion Platform (Composed of X-Table, 6DOF, Y-Table and Vibration.)
  • X-Table: Long-distance straight-line motion system. The centrifugal force in long-distance acceleration is informed to a driver.
  • 6DOF: Expression of fundamental dynamics during a vehicles run is possible.
  • Yaw-Table: The expression of motion at the time of rotations, such as an intersection and a sharp curve, is possible.
  • Vibration system: A difference at the time of running on a different road surface is expressed by fine vibration.
  • Other
  1. The various environmental sound under vehicle's run is reproduced in real time by the 5.1 Channel sound system.
  2. The cabin of vehicles are equipped, and the terminal for the power supply of PC and the Internet connection are prepared for the inside.
  3. The same steering, acceleration, and brake are used as they are in order to maintain real driving feel.
2.Multichannel projection system
The simulation environment of a vehicles run is offered at 360 degrees by using edge blending.
3.Virtual reality control unit
  • 3D road modeling and traffic simulation can be performed comfortably by UC-win/Road.
  • Eight projectors are set in a dome, after processing edge blending, a real time run simulation is projected on a screen on 360 degrees directions.
  • Direction of a projector and the projection angle are designed so as not to give trouble to driver's eyes.


UC-win/Road Bicycle simulator

Up&Coming user introduction 91st
In "traffic team instructed by " Professor Hideo Yamanaka, (Engineering Department urban design laboratory) of Tokushima University Graduate school Technology and Socio- Science Research Development, the bicycle simulator based on UC-win/Road is adopted for the development of bicycle's information display technology suitable for visual characteristics of users.
It is possible to clarify the expected angle by the differences of the size of various signs and the posting interval or the influence which viewing time gives to visibility and to acquire the knowledge used as the standard of the information presentation suitable for the environment of bicycle use. Moreover, it is possible to build various experimental conditions as well as an eye mark recorder and a head posture sensor. By introduction of experimental system using drive simulator, upon clarifying a bicycle user's visual characteristic, it is utilizable for development and examination of an effective mark set in guidance and control of a bicycle for production of a road.


The experiment using bicycle simulator
Click the image for a larger picture.
Example of signs for which the validation check are conducted by bicycle simulator.
Click the image for a larger picture.
Bicycle simulator configuration image

UC-win/Road Wheel simulator

Up&Coming Vol.91 Collaboration news introduction
The VR environment of UC-win/Road is used for the video display part of the wheelchair simulator which is the research development result of Professor Jun Kurata, Kansai University Science and Technology Department.
The model of speed and road surface resistance are used as a movement model (dynamics) of a wheelchair. UC-win/Road is utilized for the display portion. Furthermore, whether it can move inside of VR space is verified by reading the data of the actual measurement from a wheelchair simulator to UC-win/Road.
The system that by acknowledgement of danger in accident when wheelchair is used, further safety can be utilized in consideration of the individual grade and part of handicap.
Wheel chair simulator construction image
Configuration diagram and flow of cooperation part with wheel chair simulator hardware Wheel chair example by UC-win/Road MD3 character

UC-win/Road Train simulator
Train running simulator for research development, education/ training, advertisement exhibition

It has various applications
For research and development of cars and human engineering, for educating or training crews, for exhibition in museums and train expo, train driving game and so on.
From large one to small one
From entire cab including real scale crews' room, wide screen, and motion platform, to simplified version having only part of driver's console and PC screen for displaying.
Handling to both CG image and video image.
Depending on the situation, you can use CG which has high degree of freedom or video footage which excel in reality.

Generation of simulated situation which gives you a realistic feeling Generation of simulated vision with high quality image and high drawing speed, sound produced by multichannel and multispeaker, motion platform giving the real feeling of acceleration and deceleration.

Provision of the tool (VR-StudioR) which can produce the real train tracks in CG easily.

VR Video images
Large scale train simulator (image)

UC-win/Road Ship Handling Simulator NEW
  • Ship handling simulator with virtual reality

Ship handling simulator consists of a variety of 3D/VR space expression with UC-win/Road. It allows the representation of high accuracy VR space in easy method, and the construction of simulator for a variety of demanding using scenarios/event functions and motion platform techniques

This is not only for the training of sailors or students but also for the investigation of the harbor environment landscape with the simulation of its facilities.

Demonstration Simulator
  • Small type of demonstration simulator(excluding UC-win/Road)
  • Compact type for exhibition and demonstration
  • Start/Stop button
  • including handle, accelerator, and brake

Man-machine interface NEW
  • In anticipation of automatic construction

Joint research with "Japan Construction Method and Machinery Research Institute Public Works Research Institute"
(A study of informative construction by mechanization construction, 2007)

This project is a joint research with "Japan Construction Method and Machinery Research Institute Public Works Research Institute" as a part of study of informative construction by mechanization construction (2007) and still in process. To keep accuracy and efficiency of excavation by a remote control in dangerous area, the quality of the interface which shows the working condition correctly in real time to the operator is important. In this system, UC-win/Road has been mounted as a interface in operation side so that it can check current process and operating instructions in real time in 3D VR. We have also developed an operation function and implemented it and we have been checking by filed experiment.

UC-win/Road Customization System

Page Top Page Top

MR/AR

MR : Mixed Reality AR : Augmented Reality

Osaka city modeling and VR linkage system

Development of a City Presentation Method by Linking a Viewpoint Between Physical Model and VR

Associate Prof. Tomohiro Fukuda
(Graduate School of Engineering, Osaka University, Japan)
Mr. Fukuda developed a mechanism of linking a 1/300 scale physical model of Nakanoshima with VR model, Osaka, pointing the physical model with a laser pointer, having a sensor to read it and displaying in VR. He introduced the system of connecting advantages of a physical model and VR while demonstrating the prototype.

IVR exhibition 2010 The presentation in the 3rd International VR Symposium

Shibuya cloud model and interactive device

Development of Linking System for VR and Interactive Devices

Mr. Taro Narahara
(Graduate School in Harvard University, USA)
Mr. Narahara mentioned a project in which he introduced actions captured from real people into motions of figures, and represented more realistic figures on UC-win/Road.
In addition, he explained the mechanism that enabled real-time interaction by linking simulation and UC-win/Road on a real time basis through joint development of plug-ins with FORUM8.

IVR exhibition 2010 The presentation in the 3rd International VR Symposium

Face Mount System
With connecting the sensor and goggle to UC-win/Road, VR space can be shown in the goggle display by calculating the accurate head movement based on the multiple signals from each sensor.
More realistic VR simulator can be constructed compared to the normal display by connecting to drive simulator system and exhibition system.

Sensor Goggle
POLHEMUS products
The position is calculated by acquiring 6 axis information with PATRIOT(6 axis information acquisition)magnetic field generator sensor and control unit.
VUZIX products iWear VR920
Page Top Page Top

UC-win/Road for RoboCar(R)

  • Integrated car robotics platform and virtual reality
Integrated simulation system with car robotics platform scale model car "Robocar(R)" and real time VR" UC-win/Road

UC-win/Road allows the creation of large-scaled virtual reality(VR) in short time with easy method. This can provide a variety of real-time simulation. With the linkage of RoboCar(R), it can be applied for the mixed reality(MR) simulator, not only for VR. With the linkage of UC-win/Road, it is expected to be applied for a variety of simulators.

Page Top Page Top



  • Handless driving simulation
Mind&VR UC-win/Road for MindSet
Linkage of Mindset Unit which measures the brain activity with VR

Application : F1 race
Our first application using EEG based technology is a Formula 1 race. For this purpose, we developed an interface that allows to read two MindSet units, in real time (@60Hz) (Figure 3), with extraction of the Meditation and Attention factors.
The F1 race takes place on the Phoenix street circuit in Arizona, US (Figure 4). The interface was implemented as a server so the two players can race on separate machines.
The acceleration of the car is controlled by the Attention parameter, the more the user can focus his thoughts, the faster the car is moving. FORUM8 proposes the research system using biological information of brain wave.
Reading of 2 MindSet units (on left and right) with extraction of the Meditation and Attention factors for each unit (in gradient of red/green) Phoenix F1 Circuit Popular as the exhibition system for its game element

Kinect(TM) Driving Simulator
Handless driving simulation with infrared sensor

This system allows the operation of UC-win/Road by moving the arms as operating the steering in front of Kinect(TM).
The positions of both arms which are detected by Kinect(TM) are converted into steering, acceleration, braking of vehicle.

Control of vehicle and image of driving operation with infrared sensor

By the cooperation with UC-win/Road, this system allows the operation in VR space by moving the arms with gripping the virtual handle in front of Kinect(TM). The positions of both arms which are detected by Kinect(TM) are converted into steering, acceleration, braking of vehicle.
Steering operation (Right-turning, Left-turning)
Acceleration operation Braking operation
Page Top Page Top



  • Simulation / presentation system in combination with physical model and VR
"UC-win/Road Physical Model and VR System" was developed based on the idea and cooperation of Associate Professor Tomohiro Fukuda of Osaka University, a member of W16. Thanks to the technology of providing a combined operation environment of physical model and VR system, it is a new type simulation/presentation tool combing the features of both environments. The system allows you to present information effectively and efficiently to the people concerned with different background and varying knowledge levels.

UC-win/Road Physical Model and VR System(Up&Coming '11 Early Spring Issue)

Proposal and quotation of system
FORUM8 will offer the proposal and quotation of "UC-win/Road support system" based on the requirements of each customer. With UC-win/Road Support system, 3D VR simulation data can be created based on their needs. The created VR data can be modeled by exporting VR data to the physical model using 3D printer in a short time with "3D physical model service" so that the physical modeled VR system can be effectively structured. Since the created data can be produced as a 3D physical model by "3D modeling service", customers can create Physical Model and VR System effectively.

Quotation example: "Nakameguro Safety and Security Map" Physical model VR system
The proposal system with the physical model in Nakameguro where FORUM8 is located. The maintenance condition of infrastructure in the basement and the inside space of building can be checked as "Area safety and security map" where the physical model and VR are integrated, and it can be used for the consensus formation in the city re-development project.

VR data creation : About 2,700,000 Yen
3D physical model creation : About 3,600,000 Yen

* Including the cost of ARToolKit license, Web camera, laser pointer, desktop computer, 42inch display, UC-win/Road Ver.5 Advanced x1 license, customization charge of UC-win/Road, and technical fee

Total 11,600,000 Yen
Click the image for a larger picture. Click the image for a larger picture. Click the image for a larger picture.
Click the image for a larger picture.

Technical cooperation: Associate professor Tomohiro Fukuda of environment energy engineering of Osaka University

Page Top Page Top



  • Architectural civil design solution using BIM
FORUM8 provides BIM&VR solution based on BIM integrated software, Allplan and 3D VR software "UC-win/Road" as a new business model in the architecture field. In Allplan, data conversion between 3D and 2D in various format of 3D building model data such as IFC format that IAI is now proceeding to standardize by using import/export tool. In addition, the data exported in 3DS can be linked with FORUM8's products including "UC-win/Road".

Detail >> BIM&VR

BIM&VR Case studies
The following examples are case studies of architectural and civil design solutions with BIM : BIM-3D architecture modeling competition "BuildLiveTokyo2010" "BuildLiveTokyo2009II" "BuildLondonLive2009".
Click the image for a larger picture.
BuildLiveTokyo2010
(TeamF8W16)
Won the IFC Data Linkage Award
BuildLiveTokyo 2009 II
(TeamF8W16)
Won the Engineering Award
BuildLondonLive2009
(TeamBIMJapan)
Won the Grand-Prix
Page Top Page Top



  • 3D・VR for cloud computing system!

VR-Cloud(R)


This system provides the service which allows the use of virtual reality on network. The VR space opened in web browser can be operated.(Option sold separately)

VR-Cloud(R) Flash Version
・Combination of multimedia application and video streaming server by image transmitting function.
・Video creation, live webcast or Internet seminar can be created.
・To support virtual camera device on PC by using image transmitting function.
・Operation of UC-win/Road on server is possible as usual.
・The use of UC-win/Road as a conference system using VR data by share of VR space.



Detailed setting is available including video size,
frame rate, the number of users, TCP, HTTP server
Setting screen of video size, frame rate,
the number of users, TCP HTTP server

VR-Cloud(R) Standard
  • In addition to flash function, transmission rate improved greatly by a3S transmission technology.
  • The usability was improved by easier operational interface
    Display of the data for town of Shibuya by
    VR-Cloud(TM)
    (Virtual Design World Cup Shibuya sample model)

VR-Cloud(R) Collaboration
With function of Flash version, Standard version, the use of more advanced VR on cloud is possible.
  • Forum function: BBS service in 3D VR space
  • Slide function : Slide regeneration function to support presentation
Driving simulation Walking simulation, display of avatar
Click the image for a larger picture.
Annotation Features GUI using OpenGL

FORUM8 received "the Special award of the 8th CSAJ Alliance Award" from Computer Software Association of JAPAN (CSAJ)! (posted '11.06.09E
SaaS type of 3D real-time simulation software "UC-win/Road for SaaS(Current name: VR-Cloud(R))" and SaaS type of civil design software "UC-1 for SaaS" received an award "the Special award of the 8th CSAJ Alliance Award" hosted by Computer Software Association of Japan (CSAJ).

The Ministry of Economy, Trade and Industry Cloud research business adoption!
(posted '10.10.12)

As for "Agent service expenditure for Industrial technology research-and development (Next-generation high reliability, Energy-saving IT based technical development project)" (2010), "the service to use virtual 3D space supported by consensus building in cloud computing" was adopted.

Patent Pending We are currently applying patent for our technologies below.
  • a3S(Anything as a Service):Cloud transmission library (posted '11.01.04)
    Data transmission technology of 3DVR cloud, VR-Cloud(R)
      【No.】2010-290022
  • Input device for driving simulation: (posted '11.06.24) New¡ª
    Technology that enables driving simulation using a keyboard.
      【No.】 2011-137288
  • Solution for obtaining stakeholder consensus on 3D virtual space (3D bulletin board function): (posted '11.06.24) New¡ª
    Technology that creates, edits, shares etc. comments for discussion on 3DVR space.
      【No.】 2011-133352
<Reference Page>
【Up&Coming Vol.91 New Products Introduction】 a3S(Anything as a Service)

Supercomputer cloud service

FORUM8 will launch the service using HPC (High-Performance Computing). "Supercomputer cloud laboratory" was established, and we will provide the new solutions including large scale of analysis and simulation, CG rendering by using the frontline of current processing capacity of supercomputer.

VR-Studio(R) Noise simulation option
The function is almost the same as UC-win/Road version. In addition, VR-StudioŽ® version is utilized for wide range model as well as execution of supercomputer for the analysis, and it is especially strong for large scaled data process. On the other hand, as the mutual data file exchange is required between preprocessor, analysis processing and analysis processing post processor, the efficiency may fall in small scaled data.
Overall Flow Placement of sound source
Setup of sound receiving surface Sound pressure level contour
(Example in case of mobile sound source)

3D VR Cloud "VR-StudioŽ®" Service
Calculation process and data transmission of large data can be performed by linking cloud with supercomputer.

UC-win/Road、CG movie service
Large volume of CG and VR movie can be rapidly rendered by supercomputer.
Page Top Page Top

UC-win/Road Support System

  • VR/CG data generation and technical support service using UC-win/Road
Service Overview
  • Supporting advanced, complicated, and cumbersome processing!

    The service undertakes data generation tasks concerning UC-win/Road such as the generation of 3D VR simulation data, 3D models, and textures, fully empowering simulation tasks of road businesses, urban development planning, public projects, private developments, and so forth, using cost-affordable, high-quality data. The dynamic 3D CG simulation is a powerful presentation tool. This is why there have been so many achievements, awards and public recognition received since the service commenced in October 2001.

VR Modeling

Supporting line-shape/cross-section definition, diverse configuration settings, AVI output
  • Data generation of UC-win/Road and VR/CG caters to all needs and is based on a range of simulation examples. Materials such as general diagrams and line-shape calculation sheets, inputs, editing of landforms, definition of line-shapes/cross-sections, appropriate arrangement configuration and the output processing of 3-D models and textures.

3D Model/Texture

Existing and new creations of standard 3D model / textures are supported
  • A new creation of a 3D model and the texture installed as a default is supported as well as custom edits.
    Our staff will support you to help create the 3D model, texture, and the Road data creation for real-time VR presentation by UC-win/Road.

Fully supporting data generation. Users take the leading role in their presentations.
Presentation

UC-win/Road package presentation version
  • This visual tool allows engineers to control and give explanations by themselves. Presenters can explain and make changes using real-time VR and display options which offer a variety of visual representations. These features are also available in the presentation version, allowing redistribution of the program to clients.

The Generation of plane
Intersection
Interchange VR simulation of City

Page Top Page Top

Fare-paying seminar, Expert training seminar
Fare-paying seminar Charge(per person) : 15,750Yen(Tax inclusive)
UC-win/Road・VR Seminar
  • UC-win/Road VR seminar is for the user who utilize the latest 3D virtual reality in their actual works. They can learn the useful information and the operations. It also can be useful for users who has the intention to make the VR application in real in future.

UC-win/Road Advanced・VR Seminar
  • UC-win/Road Advanced seminar is for the user who make VR data model by using UC-win/Road. They can learn data creation, presentation operation by using the functions of UC-win/Road Advanced.

"FORUM8 VR Engineering authorization examination" is running!

"VR engineering authorization examination" has been carried out since December 11, 2008.
Souvenir for certified
  • Certified card
For Japanese
  • Ticket for the Fare-paying Seminar (valid for one year)
  • FORUM8 UC-win/Road book coupon -1000 Yen
For foreigners
  • Special mouse, mouse pad set

Experience seminar Charge : Free
VR-Studio(R)Experience Seminar 12d Model Experience Seminar
UC-win/Road DS Experience Seminar EXODUS・SMARTFIRE Experience Seminar
UC-win/Road for Civil 3D Experience Seminar OSCADY/TRANSYT Experience Seminar
UC-win/Road SDK Experience Seminar High-performance computing on cloud services (R) Experience Seminar
UC-win/Road-InRoads Experience Seminar VR-Cloud(R) Experience Seminar

UC-win/Road Expert Training Seminar Charge : Free

Expert training seminar for agencies / consultants
  • This seminar is for agencies which sell UC-win/Road and consultants who suggest VR business using UC-win/Road. The knowledge, techniques required to sell UC-win/Road for the prospective customer are provided. It covers the contents sales and technical issues from approaching, consulting, installing to follow -ups with practice.
The certificate is provided for all who passes the authorization examination.

UC-win/Road VR Engineer Career Path

We look forward to your application!>> SEMINAR / FARE>> SEMINARS
Page Top Page Top

Serial article on Up&Coming
イエイリ・ラボ・体験レポート Ieiri laboratory experience report

"Construction IT journalist"
- seeking the growth strategy of construction industry using IT
Ryuta Ieiri
Vol. 4 3D design system which helps road, construction design and VR simulation
UC-win/Road for Civil 3D (2011.11.01)
The afternoon on October 1, report "UC-win/Road for Civil3D Experience Seminor" in Forum 8 Tokyo head office. "UC-win/Road for Civil3D" combines the plug-in software "UC-win/RoadCivil3DPlugin" with UC-win/Road, and enables data cooperation between "Civil3D". The data format of "LandXML" which is a common file format of geographical feature data is used for data cooperation. The data cooperation of four kinds of data "Geography", "Road horizontal linear", "Road longitudinal linear" and "Road cross section" can be carried out among both software.
Practical use of point cloud data of road measured by 3D laser scanner and the town and the Cloud practical use of VR were also introduced.
Click the image for a larger picture.
The geographical feature, the alignment, and the cross-sectional information which were created by Civil3D are read into UC-win/Road, and displayed by VR The place which read into UC-win/Road the point group data which measured the rows of houses of Shibuya with 3D laser scanner
Vol. 1 Evacuation analysis EXODUSFire analysis SMARTFIRE (2011.05.01)
The theme of this time is the evacuation analysis simulation software "building EXODUS". This is the software to simulate that the evacuation behavior of people in building and tunnel when fire and earthquake occurs. It is available for designing the high-security building and infrastructure facility.
Click the image for a larger picture.
Evacuation analysis simulation software "building EXODUS" Seminar site image
Page Top Page Top

3D VR Engineering Service

We will provide 3D engineering service for VR modeling and BIM. :"3D Scanning and Modeling Service", "3D Physical Modeling Service", "3D Drawing Service"

Detail >> Up&Coming BIM&VR 3D・VR Engineering News

3D Laser Scanning and Modeling Service

By using this service, the display and edit of over 50million points data in real time will be possible. Forum 8 offers point cloud measure by 3D laser scanner, modeling and VR modeling by supply point cloud data(UC-win/Road support service). It is possible to support measuring data prepared by users and measuring data from supplier as well.

Point cloud data imported into UC-win/Road (Nihonbashi, downtown Tokyo)
Click the image for a larger picture. Click the image for a larger picture.
Scenery review by measuring data (BuildLiveTokyo2010) Hanshin Expressway
(9th 3D・VR simulation contest Grand Prix Kansai University Faculty of Informatics)
Shibuya intersection Forum 8 Tokyo head office

3D Physical Modeling Service

It's the service which outputs various 3D models, the real "model" by 3D printer, output by UC-1 series, Allplan, and of course UC-win/Road, UC-win/FRAME(3D) and so on.
Top- of- the- line Zprinter650 of Z corporation is used, and it outputs 3d model of full- color by ink-jet. Design range is Horizontal 254mmŽ×Height 381mmŽ×Depth 203mm in industry's largest class. Dividing and outputting the model at the appropriate position make it possible to create even if the model is larger than this design range. The design time is several minutes for small model and a few hours to ten hours for big models. Zprinter650 can read a lot of 3D data such as the file of STL, VRML, PLY, 3DS, ZPR.


Taishi JCT 3D model
(Taishi junction model is created by Metropolitan Expressway and is the past VR contest winner)
The 5th 3D VR Simulation Contest review
Zprinter650
Media art center
(BuildLive Tokyo2010)
Actual size of 3 dimensional Laboratory for vibration destruction (E-defense) Buzenda Hosoe area Shopping street (The photo taken by Fukudaburogu Nov 8, 2010 article "Buzenda Hosoe Yumezukuri conference : VR+3D printer model")
http://y-f-lab.jp/fukudablog/index.php?e=1046

BIM Compliant 3D Drawing Option / Report and Drawing Total Service

By using integrated BIM solution of Allplan series, 3D drawings and 2D drawings are generated.

By using BIM integration solution of Allplan series, 3D drawing and 2D drawing are created. It offers the data having the standard setting such as condition of reinforcing bar differed by the colors with Allplan viewer. You can utilize it for various study, use for 2D drawing, development to the software having BIM function (IFC data conversion). However in case of 2D drawing in Allplan, since it currently does not support SXF exchange, SXF convertible software such as our product UC-Draw is used. The end result is based on the data submission and can offer it as Allplan 3D data (supports IFC) output. It is intended for construction and civil engineering structure.
2D drawing sample generated from 3D drawing of rigid frame pier.
(Screen of Allplan-Engineering)

Sample model 1:
3D sample model of damaged and repaired status intended for current structure objects.
The damaged points of structures and 3D model image after repair are introduced. As of exposed points of rebar, it is possible to express by modeling and arrangement of rebar one by one separately. Reinforcement of arrangement and duplication can be reproduced based on the existing drawings.
It is possible not only to express the color of building frame, rebar, and aggregate by being close to the actual color, but to show exaggerated colors on 3D model. Moreover, in case the structure exists underwater,
by creating the model and changing the transmission rate, the expression of transparent water is possible. By this application, it is possible to express the underwater model as well.

Detail >> BIM&VR 3D・VR Engineering News Vol.4

Sample model 2:
Distributing reservoir sample model
We are introducing the sample cases performing the modeling of distributing reservoir used Allplan Engineering which has the strong rebar arrangement tool for RC structure. Advantage for BIM model of 3D Modeling of this sample was performed after analyzing the handwritten old drawing. Once the drawing was converted from 2D to 3D, everyone would be able to understand a complicated bar arrangement situation intuitively by displaying walk through animation and VR like this sample.
Practical use of BIM in the management and the future repair phase such as reinforcement of concrete and rebar degraded in aging, and reinforcement based on visualized rebar arrangement by creating 3 D model having attribute., For example, it is also possible to express a damage condition based on an investigation report. Moreover, structural analysis is conducted by the model created through another modeling processes as well.
Page Top Page Top

3D VR Simulation Contest

This contest has been held since 2002 where FORUM 8 received the award of Software Product of the Year.
The followings are the report which shows the awarded works in the past eight contests from our company magazine, Up&Coming.
The 9th 3D VR Simulation ContestVideo Gallery
November 19, 2010

GRAND PRIX

"Proposal of underground installation of Hanshin expressway and improved city using VR"

Faculty of Policy Studies, Kansai University
The 8th 3D VR Simulation ContestVideo Gallery
November 20, 2009

GRAND PRIX

"VR Data for Ohashi Junction of Metropolitan Expressway"

Metropolitan Expressway Company Limited
The 7th 3D VR Simulation Contest by UC-win/RoadVideo Gallery
November 20, 2008

GRAND PRIX

"Simulated driving diagnosis system using CG simulation"

National Agency for Automotive Safety & Victims' Aid
The 6th 3D VR Simulation Contest by UC-win/RoadVideo Gallery
November 27, 2007

GRAND PRIX

"Ishikawa-cho Junction Simulation"

Kanagawa Construction Bureau, Metropolitan Expressway Company Limited
The 5th 3D VR Simulation Contest by UC-win/RoadVideo Gallery
November 27, 2006

GRAND PRIX

"Simulation carried out at the Daishi junction and ventilation place"

Kanagawa Construction Bureau, Metropolitan Expressway Company Limited
The 4th 3D VR Simulation Contest by UC-win/RoadVideo Gallery
November 22, 2005

GRAND PRIX

"Matsuyama belt highway"

Ministry of Land, Infrastructure and Transport, Shikoku Regional Development Bureau,
Matsuyama Rivers and National Highway Bureau
The 3rd 3D VR Simulation Contest by UC-win/Road
November 12, 2004

GRAND PRIX

"Road management support system with virtual reality(VR)"

Road Management Technology Center
The 2nd 3D VR Simulation Contest by UC-win/Road
November 1, 2003

GRAND PRIX

"Ebina north JCT in Sagami traversing road / CG model"

NEXCO Nakanihon
(Central Nippon Expressway Co., Ltd Tokyo Branch Atsugi work office)
The 1st 3D VR Simulation Contest by UC-win/Road
November 7, 2002

GRAND PRIX

"Tokai Kanjo Expressway"

Ministry of Land, Infrastructure, Transport and Tourism, Tajimi work office
Page Top Page Top

FORUM8
